SkyTrak 6036 Parts Manual User Manual
Page 117
6036
Revised 11/97
Part Number
Qty.
Description
Item
No.
1
8262129
1
Engine, Cummins 4B3.9 Natural
2
7088413
1
Mount, Engine
3
8303640
1
Screw, Hex Hd Cap, 3/4-10 x 3.25
4
8278007
1
Mount, Vibration
5
7054351
1
Washer, Rebound
6
8310067
1
Locknut, 3/4-10 ESNA
7
8303790
10
Screw, Hex Hd Cap, M12 x 30MM
8
8307025
10
Lockwasher, M12
9
8305624
6
Locknut, 1/4-20
10
8307109
6
Washer, Flat, 1/4
11
7085422
1
Tank, Radiator Overflow (Includes Item 11A)
11A
8866341
1
Cap w/tether
12
8406103
1
Support, Hose, 0.62
13
7112434
1
Radiator (Includes Item 14)
14
8180307
1
Cap, Radiator
15
8303622
3
Screw, Hex Hd Cap, 3/8-16 x 2.0
16
8307204
4
Washer, Flat, 3/8
17
8278008
3
Mount, Vibration
18
7057141
3
Washer, Rebound
19
8305645
11
Locknut, 3/8-16
20
8904001
1
Draincock, 1/4
21
7099943
1
Shroud, Radiator
22
8303744
10
Screw, Hex Hd Cap, 3/8-16 x 1/2
23
8307004
10
Lockwasher, 3/8
24
8307106
6
Washer, Flat, 3/8
25
2712993
1
Oil Cooler, Transmission
26
2713054
1
Oil Cooler, Transmission/Hydraulic (Optional, Page 5.10.1)
27
7093783
1
Hose, Radiator, Upper
28
7093772
1
Hose, Radiator, Lower
29
8405104
3
Clamp, Hose, 2.25
30
8405203
1
Clamp, Hose, 3.0
31
8303679
2
Screw, Hex Hd Cap, 3/8-16 x 1.75
32
7112492
1
Support, Radiator
33
8303686
10
Screw, Hex Hd Cap, 3/4-10 x 2.50
34
8307010
10
Lockwasher, 3/4
35
8305017
10
Nut, Hex, 3/4-1
36
7091973
1
Crossmember, Rear Frame
37
8307222
4
Washer, Flat, M8
38
8310028
4
Screw, Hex Hd Cap, M8 x 70MM
39
8272009
1
Fan, Cooling 17" Puller
40
8320253
1
Element, Fuel Filter - Primary
41
8320250
1
Element, Fuel Filter - Secondary
42
8080613
1
Belt, Fan
43
8270220
1
Fan, Alternator (Not Shown)
44
8270221
1
Alternator (Bosch Type)
45
8033342
1
Pulley, Alternator
46
8320262
1
Element, Engine Oil Filter
47
8270416
1
Starter
48
8277143
1
Relay, Starter
49
7082452
1
Bracket, Starter
50
8303705
2
Screw, Hex Hd Cap, 1/4-20 x 0.75
51
7088352
1
Kit, Engine Coolant Heater (Optional)
ENGINE RADIATOR AND OIL COOLER MOUNTING
(CUMMINS 4B3.9 - NATURAL - S/N 6036-1526 AND AFTER)
4.8.1
