6036
Item
No.
Part Number Qty. Description
1 8401004-0470 1 Hose, Inlet
2 8405209 2 Clamp, Hose
3 8760108 1 Connector, Straight, SAE 8-10 - male JIC 37° x male str. thd. O-ring
4 8424222 1 Elbow,Tube, 45°, Barbed, SAE 32 - hose 2 "ID x 4 bolt O-ring
5 8303626 4 Screw, Hex Hd Cap, 1/2-13 x 1-1/2
6 8307007 6 Washer, Lock, 1/2
7 7054902 1 Gasket
8 8303602 2 Screw, Hex Hd Cap, 1/2-13 x 1-1/4
9 8760107 1 Connector,Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
10 2711832 1 Hose Assembly, Large Pump Outlet
11 8760325 1 Elbow, 90° SAE 12-16 - male JIC 37° x male str. thd. O-ring
12 6604862 1 Hose Assembly, Small Pump Outlet
13 8760015 1 Connector, Straight, SAE 8-8P - male JIC 37° x male NPT
14 8760005 1 Connector, Straight, SAE 16-16P - male JIC 37° x male NPT
15 2711902 1 Hose Assembly, Main Control Valve to Reservoir
16 8303713 3 Screw, Hex Hd Cap, 1/2-13 x 2-1/4 Gr 5
17 8307112 3 Washer, Flat, SAE 1/2
18 8305644 3 Locknut, 1/2-13
19 8640208 1 O-Ring #228
20 8546407 2 Clamp Half, 2"
21 8760545 1 Reducer, SAE 16-8 - male str. thd. O-ring x female internal O-ring boss
22 2712342 1 Hose Assembly, Reservoir Return
23 8760118 1 Connector, Straight, SAE 12-16 - male JIC 37° x male str. thd. O-ring
24 8760552 1 Tee, Male Branch, SAE 16-16 - male JIC 37° x male str. thd. O-ring
5.2.3
MAIN CONTROL VALVE CIRCUIT
( S/N 0E1180 AND AFTER w/ELECTRONIC CONTROLLED JOYSTICK)
Revised 9/94
