6036
9.1
Revised 11/97
OUTER BOOM
(S/N 9B0499 & BEFORE)
Part Number
Qty.
Description
Item
No.
1
7079904
1
Outer Boom (S/N 2515 & Before) (No Longer Available - Order Item 42 # 7116862)
2
8642234
4
Ring, Retaining
3
8305644
4
Nut, Lock, 1/2-13
4
7081612
1
Pin, Rod End, Slave Cylinder (S/N 2515 & Before)
5
8303772
1
Screw, Hex Hd Cap, 1/2-13 x 5 (S/N 2515 & Before)
6
8305906
2
Nut, Retaining, 5/16-18
7
7083102
1
Cover, Rear Boom (4 mtg. holes)
7A
7086452
1
Cover, Rear Boom (2 mtg. holes)
8
8307106
4
Washer, Flat, 5/16
9
8303697
4
Screw, Hex Hd Cap, 5/16-18 x 3/4
10
8307916
2
Washer, Spacer, #14 Ga
11
8307917
2
Washer, Spacer, #10 Ga
12
8303655
2
Screw, Hex Hd Cap, 5/8-11 x 4-1/2
13
8305643
2
Nut, Lock, 5/8-11
14
7081532
2
Pin, Boom Pivot
15
8303628
2
Screw, Hex Hd Cap, 1/2-13 x 3-3/4
16
7081582
2
Pin, Rod End, Hoist Cylinder
17
7081621
1
Pin, Base End, Boom Extend
18
8124126
3
Pin
19
7063472
1
Clevis, Chain
20
8307104
1
Washer, Flat, 3/4
21
8305646
1
Nut, Lock, 3/4-16
22
7081631
1
Pin, Rod End, Boom Extend
23
8303679
8
Screw, Hex Hd Cap, 3/8-16 x 1-3/4
24
7080161
2
Bar, Anti-Buckle
25
8305645
4
Locknut, 3/8-16
26
7082362
AR
Shim, Wear Pad, #10 Ga
27
8307005
18
Lockwasher, 3/8
28
8307204
18
Washer, Flat, 3/8
29
7085442
2
Spacer, Wear Pad
30
7111572
8
Wear Pad
31
7082311
18
Insert, Wear Pad
32
8303681
8
Screw, Hex Hd Cap, 3/8-16 x 3/4
33
7089781
2
Yoke, Chain
34
8127003
2
Chain, 219 Pitch x 164 -1/4
35
7063482
2
Clevis, Chain
36
8642237
6
Ring, Retaining
37
8310020
1
Screw, Socket Hd, 1/2-13 x 1-1/2
38
8310019
2
Screw, Socket Hd, 3/8-16 x 1-1/2
39
8305647
1
Locknut
40
7075611
1
Pointer
41
8303738
4
Screw, Hex Hd Cap, 3/8-16 x 7/8
42
8307113
2
Washer, Flat, 7/16
43
7116862
1
Kit, Outer Boom (Inlcudes Items 44 thru 52)
44
7116844
1
Outer Boom
45
8305643
1
Nut, Hex Lock Elastic, 5/8-11
46
7116882
1
Pin, Slave Cylinder Rod
47
8303666
1
HHCS, 5/8-11 x 5"
48
8303697
1
HHCS, 5/16-18 x 3/4"
49
7116822
1
Cover, Rear Boom
50
8305906
2
Nut, Retainer, 5/16-18
51
8307004
1
Washer, Lock, 5/16"
52
8303739
1
HHCS, 5/16-18 x 1-1/4
