Axle steering joints 3.13 – SkyTrak 6036 Parts Manual User Manual
Page 79
6036
AXLE STEERING JOINTS
3.13
Part Number
Qty.
Description
Item
No.
Note: Quantites are for one axle
1
8032951
1
Shaft & Joint Assembly, Right Rear, Left Front (Includes item 2 thru 7)
(Not Shown)
8033200
Shaft & Joint Assembly, Left Rear, Right Front (Includes Items 2, 3, 4, 5,
6 & 8)
2
8032868
1
Shaft, Outer
3
See Kits
2
Cross Assembly
4
See Kits
8
Bearing Race Assembly
5
See Kits
8
Ring, Snap
6
8032874
1
Yoke, Center
7
8032869
1
Shaft, Inner Yoke (Not Shown) - Right Rear & Left Front
8
8032870
1
Shaft, Inner Yoke - Left Rear & Right Front
9
8032981
2
Seal, Oil (See Kits below and on Pages 3.11 & 3.12)
10
8032815
2
Seal, Oil (See Kits below and on Pages 3.11 & 3.12)
11
8032887
2
Bushing, Spindle (See Kits)
12
8032866
1
Knuckle Assembly, Left Rear, Right Front (Includes Item 13)
8032867
1
Knuckle Assembly, Not Shown, Right Rear, Left Front (Includes Item 13)
13
8032878
12
Stud, Dowel
14
8032875
24
Nut, Lock
15
8032876
24
Washer, Flat
16
8032877
4
Fitting, Grease
17
8033824
16
Screw, Cap, Hex Hd
18
8032855
16
Washer, Flat
19
8032880
4
Cap, King Pin
20
8032881
AR
Shim, Formed
21
8032882
AR
Shim, Formed
22
8032979
4
Seal, Oil (See Kits below & on Pages 3.11 & 3.12)
23
8032883
4
Cone, Roller Bearing
24
8032885
4
Cup, Roller Bearing
25
8032886
4
Retainer, Grease
Kits
26
7091562
AR
Axle Shaft Service Kit (Includes one of each items 9, 10 & 11 &
Instruction sheet)
27
8033492
2
Cross & Bearing Kit (Includes one of item 3 & four of items 4 & 5)
Revised 11/97
