SkyTrak 6036 Parts Manual - Manual (Page 137)

6036
MAIN CONTROL VALVE CIRCUIT
(S/N 9B0499 AND BEFORE)
Part Number Qty. Description
Item
No.
1 8320255 1 Head, Filter (See NOTE)
2 8320240 1 Element, Filter (See NOTE)
3 8401004-0470 1 Hose, Inlet
4 8405209 2 Clamp, Hose
5 8424003 1 Hose Fitting, Beaded, SAE 32-32P - 2" ID x male NPT
6 8424222 1 Hose Fitting, Elbow, Tube, 45° Barbed, SAE 32 - hose 2 " ID x 4 bolt O-ring
7 8303626 4 Screw, Hex Hd Cap, 1/2-13 x 1-1/2
8 8307007 6 Lockwasher, 1/2
9 7054902 1 Gasket
10 8303625 2 Screw, Hex Hd Cap, 1/2-13 x 1-1/4
11 8760111 1 Connector, Straight, SAE 8-12 - male JIC 37° x male str. thd O-ring
12 2711832 1 Hose Assembly, Large Pump Outlet
13 8760325 1 Elbow, 90° SAE 12-16 - male JIC 37° x male str. thd. O-ring
14 2711912 1 Hose Assembly, Small Pump Outlet
15 8540048 1 Bushing, Hex, 1-1/4 " NPT x 1 " NPT (See NOTE)
16 8760005 1 Connector, Straight, SAE 16-16P - male JIC 37° x male NPT
17 2711902 1 Hose Assembly, Main Control Valve to Filter
18 8551621 1 Pipe, 1-1/4 x 11 (See NOTE)
19 8760002 1 Connector, Straight, SAE 10-8P - male JIC 37° x male NPT
20 2711922 1 Hose Assembly, Emergency Pump Inlet
21 8760115 1 Connector,Straight, SAE 10-10 - male JIC 37° x male str. thd. O-ring
22 8303713 3 Screw, Hex Hd Cap, 1/2-13 x 2-1/4
23 8307112 3 Washer, Flat, SAE 1/2
24 8305644 3 Locknut, 1/2-13
25 8303621 2 Screw, Hex Hd Cap, 3/8-16 x 1-1/2
26 8307005 2 Lockwasher, 3/8
27 8760311 1 Elbow, 90° SAE 6-6 - male JIC 37° x male str. thd. O-ring
28 2712182 1 Hose Assembly, Emergency Pump Outlet
29 8760102 1 Connector, Straight, SAE 16-16 - male JIC 37° male str. thd. O-ring
30 8760109 1 Connector,Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring
31 8640208 1 O-Ring, #228
32 8546407 2 Clamp Half, 2"
NOTE: Items 1, 2, 15 and 18 are not used with reservoirs converted to
in-tank filters. See Sheet 6.1 for reservoir conversion kit.
Revised 9/94
5.2
