6036
5.6
Part Number Qty. Description
Item
No.
1 8902109 1 Valve, Steer Select
2 8902116 1 Valve, Park Lock Release
3 8902224 1 Valve, Sequence
4 8902225 1 Valve, Pressure Reducing
5 8902651 1 Valve, Relief
6 8902230 1 Valve, Sequence
7 8760110 3 Connector, Straight, SAE 6-8, male JIC 37° x male str. thd. O-ring
q 8 8760013 1 Connector, Straight, SAE 8-4P, male JIC 37° x male NPT
9 8760010 1 Connector, Straight, SAE 4-4P, male JIC 37° x male NPT
10 8760432 1 Tee, Male Run, SAE 6-4P, male JIC 37° x male NPT
11 8760107 1 Connector, Straight, SAE 8-10, male JIC 37° x male str. thd. O-ring
12 8760510 4 Tee, Male Run, SAE 8-8, male JIC 37° x male str. thd. O-ring
13 8760449 2 Tee, Male Run, SAE 6-6, male JIC 37° x male str. thd. O-ring
14 8760108 2 Connector, Straight, SAE 10-10, male JIC 37° x male str. thd. O-ring
15 8760464 1 Tee, Male Run, SAE 10-10, male JIC 37° x male str. thd. O-ring
16 7081783 1 Tube Assembly
17 7081731 3 Tube Assembly
18 7081773 1 Tube Assembly
19 8303746 4 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
20 8307004 6 Lockwasher, 5.16
21 8307106 4 Washer, Flat, 5/16
22 8305006 6 Nut, Hex, 5/16-18
23 8304631 4 Screw, Socket Hd Cap, #10-24 x 2
24 8304608 2 Screw, Socket Hd Cap, 5/16-18 x 1-1/2
25 8303090 2 Screw, Hex Hd Cap, 1/4-20 x 1-3/4
26 8307002 4 Lockwasher, 1/4
27 8307102 2 Washer, Flat, 1/4
28 8305004 4 Nut, Hex, 1/4-20
29 8303082 2 Screw, Hex Hd Cap, 1/4-20 x 3
30 8760313 1 Elbow, 90°, SAE 6-8, male JIC 37° x male str. thd. O-ring
31 8760311 1 Elbow, 90°, SAE 6-6, male JIC 37° x male str. thd. O-ring
32 8760307 1 Elbow, 45°, SAE 8-8, male JIC 37° x male str. thd. O-ring
33 8278008 4 Mount, Rubber
34 7081693 1 Plate, Valve Mounting
35 8902111 1 Subplate, Valve
36 8760407 3 Nut, SAE 8 - JIC 37°
37 8760458 3 Reducer, Tube End, SAE 8-6, JIC 37°
38 2711382 1 Hose Assembly
39 8304042 4 Bolt, Carriage, 3/8-16 x 2
40 8307110 4 Washer, Flat Heavy, 3/8
41 7057141 4 Washer, Rebound
42 8307005 4 Lockwasher, 3/8
43 8305008 4 Nut, Hex, 3/8-16
Revised 11/97
VALVE PLATE ASSEMBLY
(S/N 8F0235 & BEFORE)
