6036
9.9.2
Revised 11/97
SIDE TILT CARRIAGE - OPTIONAL
(S/N 9B0473 THRU 6036-1316)
Part Number Qty. Description
Item
No.
1 7089044 1 Carriage, Side Tilt - 48"
2 7089054 1 Carrige, Side Tilt - 60"
3 7098354 1 Carrige, Side Tilt - 72"
4 7065482 2 Pad Wear
5 8303739 2 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
6 8305626 2 Locknut, 5/16NC
7 7085154 1 Base, Pivot
8 7077501 1 Pin, Cylinder Base
9 7077511 1 Pin, Cylinder Rod
10 7077481 2 Spacer
11 8065643 1 Bushing, Self Align
12 8642001 1 Ring, Snap
13 8642235 4 Ring, Snap
14 8760117 2 Connector, Straight, SAE 6-6 - male JIC° x amle str. thd. O-ring
15 8584001 1 Tie Wrap
16 2711992 2 Hose Assembly
17 8760030 2 Connector, Straight, SAE 6-6P - male JIC° x male NPT
18 8420056 1 Quick Disconnect, Male 6/6" NPT
19 8420057 1 Quick Disconnect, Female 6/6" NPT (Includes Item 18A)
19A 8640027 1 O-Ring, Viton for High Temp. Application of Item 18
20 8541433 1 Plug, Pipe Hex, Socket, 1/8
21 8420058 1 Cap, Dust, SAE 6
22 8420059 1 Plug, Dust, SAE 6
23 8582406-0090 1 Moulding
24 7085411 1 Pin, Pivot
25 7085501 1 Collar, Locking Pin
26 8303770 1 Screw, Hex Hd Cap, 3/8-16 x 2-3/4
27 8305645 1 Locknut, 3/8-16 ESNA
28 7083912 1 Shaft, Fork Pivot, 48 x 2.00"
29 7084972 1 Shaft, Fork Pivot, 60 x 2.00" (Not Shown)
30 7084942 1 Shaft, Fork Pivot, 72 x 2.00" (Not Shown)
31 7086471 2 Hub, Lock
32 8303634 2 Screw, Hex Hd Cap, 5/8-11 x 4
33 8305643 2 Locknut, 5/8-11
34 7048233 2 Fork, Pallet 48 x 4 x 1.75" (3000 lb Rating)
7085673 2 Fork, Lumber 60 x 5 (Not Shown) (22" Fork Drop)
7092793 2 Fork, Lumber 60 x 5 (Not Shown) (24" Fork Drop) (Service in Pairs when
replaicing 22" drop forks)
7085073 6 Fork, Blocking (Not Shown)
KITS
35 7096712 1 Conversion Kit, Attachment, Size 6 to Size 8 Quick Couplers
(Includes Items 17, 18, 19, 21 & 22, Page 9.9.3 &
P/N 8760341elbow for Auger Mount to replace corresponding
parts on these attachments)
