Page 205
6036
BOOM HOIST CYLINDER
Part Number
Qty.
Description
Item
No.
7129252
2
Cylinder, Boom Hoist - TJB (Includes Items 1 thru 15)
2713793
2
Cylinder, Boom Hoist - TJB (Optional, Ported for Load Indicator) (Includes Items 1 thru
15)
1
8902247
1
Valve, Counterbalance (For 7129252)
2
8032712
1
Plug
3
NSS
1
Tube, Cylinder (For 7129252)
NSS
1
Tube, Cylinder (For 2713793)
4
8032714
1
Nut
5
8032715
1
Plug
6
8032716
1
Piston
7
See Kits
1
Seal, Piston
8
See Kits
1
O-Ring
9
See Kits
1
O-Ring
10
See Kits
1
Ring, Backup
11
8032717
1
Gland
12
8032719
1
Rod
13
See Kits
1
Wiper
14
See Kits
1
Seal, Rod
15
8065640
1
Bushing
16
80520013
2
Fitting, Grease, 1/8 NPT
KITS
17
8032718
1
Seal Kit, Boom Hoist Cylinder (Includes Items 7, 8, 9, 10, 13, 14)
18
8205656
1
Seal Kit, Counterbalance Valve (Includes 3 O-Rings & 3 Backup Rings)
Part Number
Qty.
Description
Item
No.
2711543
2
Cylinder, Boom Hoist - BHE (Includes Items 1 thru 25)
1
8033143
1
Screw, Hex Hd Cap
2
NSS
1
Barrel
3
8033153
1
Plug, Sealing
4
8033145
1
Plug, Sealing
5
See Kits
1
O-Ring
6
8033131
1
Plug
7
8902843
1
Cartridge Valve, Counterbalance (Includes Items 8 thru 12)
8
See Kits
1
O-Ring
9
See Kits
1
Ring, Backup
10
See Kits
1
O-Ring
11
See Kits
2
Ring, Backup
12
See Kits
1
O-Ring
13
8033140
1
Piston
14
See Kits
1
Bearing
15
See Kits
1
Seal & Expander Assembloy
16
See Kits
2
Ring, Backup
17
See Kits
1
O-Ring
18
See Kits
1
O-Ring
19
See Kits
1
Wiper
20
See Kits
1
Seal
21
See Kits
1
O-Ring
22
8033134
1
Head
23
See Kits
1
Ring, Backup
24
8033132
1
Rod
25
8065640
1
Bushing
26
8520013
1
Fitting, Grease, 1/8 NPT
KITS
27
8205668
1
Seal Kit, Boom Hoist Cylinder (Includes Items 5, 8, thru 12, 14 thru 21 and 23)
28
8033425
1
Seal Kit, Counterbalance Valve (Includes Items 8 thru 12)
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
IMPORTANT !
Before ordering internal service parts, you must first identify the cylinder by the
manufacturer's stamping (see illustrations). The BHE cylinders are no longer
available as individual complete assemblies. You must replace individual BHE
cylinders with a pair of the same TJB cylinders.
6.4
Revised 9/94
