6036
Revised 11/97
Part Number
Qty.
Description
Item
No.
1
7089114
1
Harness, Cab (Obsolete)
7114754
1
Harness, Cab (Includes Items 1A & 1B)
1A
8220882
2
Connector, Solenoid (Includes Item 1B)
1B
8688026
2
Seal, Connector (Not Shown)
2
7112511
1
Motor Kit, Windshield Washer/Wiper
3
8033201
1
Switch, Windshield Washer/Wiper
4
8223442
1
Switch, Test
5
8580312
1
Boot, Test Switch
6
8223405
1
Button, Horn
7
8580311
1
Boot, Horn Button
8
8464212
1
Gauge, Fuel
9
8466305
1
Gauge, Warning Lights
10
8467014
1
Hourmeter
11
8223220
1
Switch, Steer Select
12
8220050
2
Terminal, Male
13
8033065
1
Washer Reservoir Assembly
14
8223436
1
Switch, Ignition
15
8223438
1
Key, Ignition (w/Keys)
16
8033078
1
Fan, Circulation
17
8229233
3
Fuse, 7.5 Amp (4 Required on Closed Cab)
18
8229234
2
Fuse, 10 Amp
19
8229235
1
Fuse, 20 Amp (Optional Light Package)
20
8305004
2
Nut, Hex, 1/4
21
8307109
2
Washer, Flat, 1/4
22
8307005
2
Lockwasher, Internal Tooth, 3/8
23
8305002
2
Nut, Hex, #10
24
8229415
1
Circuit Breaker, 40 Amp
25
8223024
1
Switch Kit, Heater
26
8584001
5
Wrap, Tie (Not Shown)
27
8307002
3
Lockwasher, 1/4
28
8223444
1
Switch, Brake
29
8223445
1
Guard, Switch
30
8307003
2
Lockwasher, #10
31
8469028
1
Warning Light, Brake
32
8582007
3
Clip, Spare Fuse
33
8220008
1
Terminal, Ring #10
34
8160621
1
Switch, Reverse
35
8032756
2
Solenoid, Steer Select Valve
36
8584003
1
Tie Wrap
NOTE: The following protective parts are used with Harness 7089114 only
in place of items 17, 18 & 19
37
8229215
2
Circuit Breaker, 6 Amp (3 Required on Closed Cab)
38
8229216
2
Circuit Breaker, 10 Amp
39
8229226
1
Circuit Breaker, 40 Amp
40
7047041
1
Wire Assembly (Closed Cab Only)
41
8229218
1
Bracket, Circuit Breaker
42
7084202
1
Wire Assembly
ELECTRICAL SYSTEM - CAB HARNESS
(S/N 9B0501 & AFTER)
7.1.1
