6036
Part Number Qty. Description
Item
No.
1 2711882 2 Hose Assembly, Attachment Tilt Cylinder
2 7082673 1 Tube Assembly, Attachment Tilt Cylinder
3 7084673 1 Tube Assembly, Attachment Tilt Cylinder
4 8760045 2 Union, Bulkhead, Straight, SAE 8 - male JIC 37°
5 8760107 2 Connector, Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
6 2711872 1 Hose Assembly, Slave Cylinder Retract
7 2712122 1 Hose Assembly, Slave Cylinder Extend
8 2712112 2 Hose Assembly, Slave Tube
9 2711892 2 Hose Assembly, Frame Tilt Cylinder
10 8760110 2 Connector, Straight, SAE 6-8 - male JIC 37° x male str. thd. O-ring
11 8760134 2 Connector, Straight, SAE 6-4 - male JIC 37° x male str. thd. O-ring
12 8760535 4 Reducer, SAE 12-8 - male str. thd. O-ring x female internal O-ring boss
13 8760313 2 Elbow, 90° SAE 6-8 - male JIC 37° x male str. thd. O-ring
14 8760510 2 Tee Male Run, SAE 8-8 - male JIC 37° x male str. thd. O-ring
15 8769139 1 Clamp Set, Twin (2 halves, 3/4 ID)
16 8769128 2 Plate, Cover
17 8303752 2 Screw, Hex Hd Cap, 5/16-18 x 3
18 8305626 1 Locknut, 5/16-18
19 8769122 3 Clamp Set, Twin Tube (2 halves, 5/8 ID)
20 8769123 3 Plate, Clamp Top
21 8303739 3 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
22 8769129 2 Clamp Set, Single (2 halves, 5/8 ID)
23 8769146 2 Cover, Clamp
24 8303743 4 Screw, Hex Hd Cap, 1/4-20 x 1-1/2
NOTE: FOR RETROFIT INFORMATION ON
AUXILIARY HYDRAULIC CIRCUITS AND
RELATED COMPONENTS, REFER TO
THE AUXILIARY HYDRAULIC CIRCUIT
- OPTIONAL PAGES.
5.4
Revised 11/97
ATTACHMENT TILT, SLAVE & FRAME TILT CIRCUITS
(S/N 9B0499 & BEFORE)
