SkyTrak 6036 Parts Manual - Manual (Page 227)

6036
6.12
Part Number Qty. Description
Item
No.
8902119 1 Main Control Valve - Auxiliary Hydraulics (Includes Items 1 thru 42)
1 8902504 1 Section, Inlet (Includes one of Item 6)
2 8033215 1 Section, Outlet
3 8033158 1 Section, Boom Hoist (Includes Items 6 thru 17)
4 8033159 2 Section, Boom Extend/Attachment Tilt (Includes Items 6 thru 17)
5 8033160 2 Section, Frame Tilt (Includes Items 6 thru 16 & 18)
6 See Kits 1 O-Ring
7 See Kits 2 Screw, Cap, Socket Hd
8 See Kits 1 Cap, Spool
9 See Kits 1 End, Spool
10 See Kits 2 Seat, Spring
11 See Kits 2 Wiper
12 See Kits 2 O-Ring
13 See Kits 2 Plate, Seal
14 See Kits 2 Screw, Round Hd Machine
15 See Kits 1 Poppet, C.V.
16 See Kits 1 Spring
17 8033161 1 Spring (Used on Items 3, 4 & 42)
18 8033162 1 Spring (Used on Item 5 Only)
19 8033216 1 Relief Valve, Main - Preset at 3000 ± 50 psi (Includes Items 20 thru 27)
20 See Kits 2 O-Ring
21 See Kits 1 Ring, Backup
22 See Kits 1 O-Ring
23 See Kits 1 O-Ring
24 See Kits 1 Ring, Backup
25 See Kits 1 Spring
26 See Kits 1 Spring
27 See Kits 2 O-Ring
28 8033164 5 Relief Valve, Port - Preset at 2650 ± 50 psi (Includes Items 30 thru 38)
29 8033150 2 Relief Valve, Port - Preset at 1200 ± 50 psi (Includes Items 30 thru 37 & 39)
30 See Kits 1 O-Ring
31 See Kits 1 Ring, Backup
32 See Kits 1 O-Ring
33 See Kits 1 O-Ring
34 See Kits 1 Ring, Backup
35 See Kits 1 Spring
36 See Kits 1 O-Ring
37 See Kits 2 O-Ring
38 See Kits 1 Spring (Used on Item 28 Only)
39 See Kits 1 Spring (Used on Item 29 Only)
40 See Kits 6 Nut, Special
41 See Kits 3 Tie Rod
42 8902524 1 Section, Auxiliary Hydraulics (Includes Items 6 thru 17)
KITS
43 8902525 1 Rebuild Kit For Sections Items 3, 4 & 42 (Includes 6 of Item 6 and listed
quantities of Items 7 thru 17)
44 8902526 1 Rebuild Kit For Section Item 5 (Includes 6 of Item 6 and listed
quantities of Items 7 thru 16 & 18
45 8033218 1 Seal & Spring Kit For Main Relief Valve Item 19 (Includes Items 20 thru 27)
46 8902465 1 Seal & Spring Kit For Port Relief Valve Item 28 (Includes Items 30 thru 38)
47 8033219 1 Seal & Spring Kit For Port Relief Valve Item 29 (Includes Items 30
thru 37 & 39)
48 8902523 1 Tie Rod Kit (Includes Items 40 & 41)
Revised 11/97
MAIN CONTROL VALVE - AUXILIARY HYDRAULICS
(S/N 9B0499 & BEFORE)
