Page 81
6036
WHEEL END - REAR AXLE ONLY
(W/O SERVICE BRAKES)
3.14
Part Number
Qty.
Description
Item
No.
Note: Quantites for items 2 thru 31 are for one wheel assembly
1
8032938
2
Wheel End Assembly, Rear Axle (Includes Items 2 thru 31)
2
8032906
18
Screw, Hex Hd, Self Locking
3
8032918
1
Planetary Gear Assembly (Includes Items 4 thru 13)
4
8032903
1
Flange, Drive, Planetary
5
8032895
1
Plug, Pipe
6
8032894
1
Plug, Hex Hd
7
8032937
3
Pin, Roller
8
8032899
3
Shaft, Planet Gear
9
8032896
1
Washer, Drive Flange
10
8032901
6
Washer, Keyed
11
8032898
150
Bearing Single Roller
12
8032897
3
Washer, Planet Gear
13
8032902
3
Gear, Spur
14
8032908
1
Ring, Snap
15
8032939
1
Gaer, Spur
16
8032940
1
Spacer, Flat
17
8032941
1
Gear, Planetary Ring
18
8032943
1
Nut, Lock
19
8032942
1
Pin, Roll
20
8032944
1
Cone, Roller Bearing
21
8033225
1
Hub Assembly (Includes Items 22 thru 26)
22
8032934
1
Cup, Roller Bearing
23
8032933
1
Hub, Planetary
24
8032893
10
Bolt, Wheel, RH
25
8032935
1
Cup, Roller Bearing
26
8032936
1
Slinger, Hub Oil
27
8786516
10
Nut, Wheel
28
8032945
1
Cone, Roller Bearing
29
8032988
1
Seal, Oil (See Kit, Page 3.12)
30
8032948
1
Spindle Assembly (Includes Item 30A)
30A
8032977
1
Bushing, Spindle
31
8032982
1
Seal, Oil (See Kit, Page 3.12)
32
8522042
AR
Fluid, Special Wet Disc Brake, 1 Gal. (Not Shown)
Revised 11/97
