Page 91
6036
TIRE ROD & STEERING CYLINDER MOUNTING
3.16
Part Number
Qty.
Description
Item
No.
Note: Quantites listed are for one axle
1
8033252
1
Tie Rod Assembly (Includes itesm 2 thru 9)
2
8032928
1
Tube, Tie Rod
3
8032929
1
Socket Assembly, 1-1/8-16 (Includes Nut, Cotter Pin & Boot)
4
8032816
1
Boot
5
8033965
1
Cotter Pin
6
8032930
2
Clamp Assembly
7
8032931
1
Socket Assembly, 1-1/8-12 (Includes Nut, Cotter Pin & Boot)
8
8032816
1
Boot
9
8033965
1
Cotter Pin
10
8340025
4
Socket Assembly, Steer Cylinder (Includes Nut, Cotter Pin & Boot)
11
8032816
AR
Boot
12
8033965
AR
Cotter Pin
Revised 11/97
