6036
Part Number Qty. Description
Item
No.
MAIN FRAME
1.1
1 8642224 6 Ring, Snap, 2.0 Dia
2 7081571 2 Pin, Hoist Cylinder
3 7081601 1 Pin, Slave Cylinder
4 Consult Factory 1 Frame Weldment
5 8221020-0600 AR Conduit,1 ID x 5 Ft. - Cut to Fit
6 8221011-0600 AR Conduit, 1/2 ID x 5 Ft. - Cut to Fit
7 8310093 AR Shim, 0.075 Thk
8 8040229 1 Axle, Front (S/N 6036-2343 and Before)
8040250 1 Axle, Front (S/N 6036-2344 and After)
9 8040228 1 Axle, Rear (w/o Service Brakes)
8040232 1 Axle, Rear (w/ Service Brakes) (S/N 6036-1305 and Before)
8040241 1 Axle, Rear (w/ Service Brakes) (S/N 6036-1306 thru 2337)
8040251 1 Axle, Rear (w/ Service Brakes) (S/N 6036-2338 and After)
10 7084911 AR Shim, 0.010 Thk
11 8305017 4 Nut, Hex, 3/4-10
12 7081551 1 Pin, Frame Leveling
13 7081561 2 Block, Mounting
14 8642207 2 Ring, Snap, 1.5 Dia
15 8303731 4 Screw, Hex Hd Cap, 3/4-10 x 5-1/2
16 8642207 2 Ring, Snap, 1.5 Dia
17 7081541 1 Pin, Frame Leveling Cylinder
18 8307010 4 Lockwasher, 3/4
19 8065637 2 Bushing, 2-1/2 ID
20 8065636 2 Bushing, 2 ID
21 8305643 2 Locknut, 5/8-11 (See Kits)
22 8303655 2 Screw, Hex Hd Cap, 5/8-11 x 4-1/2, Gr 5 (See Kits)
23 7096062 2 Pin, Axle Pivot (See Kits)
ITEMS 24 THRU 27, FOR MACHINES S/N 9F0694 AND BEFORE
24 7083353 1 Counterweight (no longer available) - See Kits
25 8307107 1 Washer, Flat, 5/8
26 8307009 1 Lockwasher, 5/8
27 8303633 1 Screw, Cap, Hex Hd, 5/8-11 x 3-1/2
ITEMS 28 THRU 34, FOR MACHINES S/N 9F0695 AND AFTER
28 5724302 AR Washer, Shim, 0.060 Thk
29 7089913 1 Counterweight
30 8310051 4 Screw, Hex Hd Cap, 1-8 x 4, Gr 5
31 8305021 4 Nut, Hex 1-8
32 8310066 AR Washer, Flat, 1
33 7088341 4 Spacer
34 8307012 4 Lockwasher, 1
KITS
35 7086851 2 Pin and Hub Kit (Includes Items 21, 22, 23 and Locking Hub)
36 7096622 1 Counterweight Kit for item 24 (Includes Hardware)
Revised 9/94
