SkyTrak 6036 Parts Manual - Manual (Page 179)

6036
5.8.1
Part Number Qty. Description
Item
No.
1 8584007 2 Plastic Wrap
2 2712172 2 Hose Assembly, 3/8 ID
2712922 2 Hose Assembly, 1/2 ID (For use with Quick Coupler Kit)
3 8305626 1 Locknut, 5/16-18 (Existing part shown on Page 5.4.1)
4 8769129 2 Clamp Set, Single (2 halves, 5/8 ID)
7097491 4 Clamp Half, 3/4 ID (For interim use with 1/2 ID hose)
4A 8769155 2 Bolt, Stacking
4B 8769156 2 Plate, Stacking
4C 8769129 2 Clamp Set, Single (2 halves, 5/8 ID) (Existing part shown on Page 5.4.1)
5 8303728 4 Screw, Hex Hd Cap, 1/4-10 x 2-3/4
5A 8769146 2 Plate, Cover
6 8769126 3 Clmap Set, Single (2 halves, 1/2 ID)
7 8303690 2 Scew, Hex Hd Cap, 5/16-18 x 2
8 7084683 2 Tube Assembly
9 8584002 1 Tie Wrap
10 2712582 2 Hose Assembly
11 8760045 2 Union, Bulkhead, Straight, SAE 8 - male JIC 37°
12 8769139 1 Clamp Set, Single (2 halves, 3/4 ID) (Existing part shown on Page 5.4.1)
12A 8769139 1 Clamp Set, Single (2 halves, 3/4 ID)
13 8310081 1 Screw, Hex Hd Cap, 5/16-18 x 5 (Existing part shown on Page 5.4.1)
14 8760143 1 Connector, Long, SAE 8-8 - male JIC 37° x male str. thd O-ring
15 8420057 1 Quick Disconnect, Female 3/8 NPT (See also Item 15A)
15A 8640027 1 O-Ring, Viton - For high temperature Application of Item 15
16 8420059 1 Plug, Dust, SAE 6
17 8420056 1 Quick Disconnect, Male 3/8 NPT (See also Item 17A)
18 8420058 1 Cap, Dust, SAE 6
19 8303620 1 Screw, Hex Hd Cap, 3/8-16 x 1
20 8307005 1 Lockwasher 3/8
21 8540001 2 Nipple, Hex, 3/8 NPT
22 7085491 1 Plate, Junction
23 8760107 1 Connector, SAE #8 - JIC #8
24 8769128 2 Plate, Cover
KITS
25 7096862 1 Kits, Quick Couplers
8430005 1 Quick Disconnect, Female 3/4-16 ORB (Item 20, Page 5.8.2)
8420055 1 Plug, Dust, SAE 8 (Item 21, Page 5.8.2.)
8430006 1 Quick Disconnect, Male 3/4-16 ORB (Item 22, Page 5.8.2)
8420053 1 Cap, Dust, SAE 8 (Item 23, Page 5.8.2)
8760142 2 Connector, Swivel Nut, SAE 8-8 (Item 24, Page 5.8.2)
8760045 2 Union, Bulkhead, Straight, SAE 8 - male JIC 37° (Item 25, Page 5.8.2)
5713331 4 Washer, Flat (Used on forks with 0.983 dia. mtg. holes) (Item 26, Page 5.8.2)
26 7097662 1 Kit, Inner Boom (For auxiliary hydrulic retrofit)
8303743 4 Screw, Hex Hd Cap, 1/4-10 x 1-1/2 (Item 5, Page 5.8.2)
8769153 2 Plate, Cover (Item 6, Page 5.8.2)
8769154 2 Clamp Set, Single (2 halves, 3/4 ID) (Item 7, Page 5.8.2)
8769155 4 Bolt, Stacking (Item 8, Page 5.8.2
8769156 2 Plate, Stacking (Item 9, Page 5.8.2)
7097644 1 Inner Boom (Item 1, Page 9.3)
Revised 11/97
AUXILIARY HYDRAULIC CIRCUIT - OPTIONAL
(S/N 9B0500 THRU 6036-1316)
