6036
5.6.1
Part Number Qty. Description
Item
No.
Revised 11/97
VALVE PLATE ASSEMBLY
(S/N 8G0236N THRU S/N 9B0499)
1 8902109 1 Valve, Steer Select
2 8902116 1 Valve, Park Lock Release
8902134 1 Valve, Park Lock Release (For units with Declutch)
3 8902224 1 Valve, Sequence
4 8902225 1 Valve, Pressure Reducing
5 8902651 1 Valve, Relief
6 8760110 4 Connector, Straight, SAE 6-8, male JIC 37° x male str. thd. O-ring
7 8760013 1 Connector, Straight, SAE 8-4P, male JIC 37° x male NPT
8 8760010 1 Connector, Straight, SAE 4-4P, male JIC 37° x male NPT
9 8760432 1 Tee, Male Run, SAE 6-4P, male JIC 37° x male NPT
10 8760107 1 Connector, Straight, SAE 8-10, male JIC 37° x male str. thd. O-ring
11 8760510 3 Tee, Male Run, SAE 8-8, male JIC 37° x male str. thd. O-ring
12 8760449 2 Tee, Male Run, SAE 6-6, male JIC 37° x male str. thd. O-ring
13 8760108 2 Connector, Straight, SAE 10-10, male JIC 37° x male str. thd. O-ring
14 8760464 1 Tee, Male Run, SAE 10-10, male JIC 37° x male str. thd. O-ring
15 7081783 1 Tube Assembly
16 7081731 3 Tube Assembly
17 7081773 1 Tube Assembly
18 8303746 2 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
19 8307004 8 Lockwasher, 5.16
20 8307106 4 Washer, Flat, 5/16
21 8305006 8 Nut, Hex, 5/16-18
22 8304631 4 Screw, Socket Hd Cap, #10-24 x 2
23 8304608 2 Screw, Socket Hd Cap, 5/16-18 x 1-1/2
24 8303090 2 Screw, Hex Hd Cap, 1/4-20 x 1-3/4
25 8307002 2 Lockwasher, 1/4
26 8307102 2 Washer, Flat, 1/4
27 8305004 2 Nut, Hex, 1/4-20
28 8303786 2 Screw, Hex Hd Cap, 5/16-18 x 2-1/4
29 8278008 4 Mount, Rubber
30 7081693 1 Plate, Valve Mounting
31 8902111 1 Subplate, Valve
32 8304042 4 Bolt, Carriage, 3/8-16 x 2
33 8307110 4 Washer, Flat Heavy, 3/8
34 7057141 4 Washer, Rebound
35 8307005 4 Lockwasher, 3/8
36 8305008 4 Nut, Hex, 3/8-16
KITS
37 7093242 1 Kit, Declutch Conversion (Refer to sheet 5.5.2 for Kit Parts)
