6036
1
7126684
1
Harness, Engine
7096874
1
Harness, Engine (Obsolete)
2
8270014
2
Battery, 12 Volt
3
7114542
1
Cable, Battery - Negative
3A
7068651
1
Cable, Starter Ground (Not used with Cable 7114542) (Not Shown)
4
7080192
1
Cable, Battery - Positive
5
8310202
1
Screw, Washer Hd, Type B, 3/8 x 3/4
6
8270602
1
Horn
7
7082261
1
Wire Assembly (Not used with harness 7098864)
8
7093442
1
Backup Alarm, Retrofit for ECCO Brand (Includes Hardware)
8270617
1
Alarm, Backup - Velvac Brand Replacement
9
8303615
2
Screw, Hex Hd Cap, 1/4-20 x 1-1/4 Gr 5 (Velvac Brand Only)
10
8305004
2
Nut, Hex, 1/4-20 (Velvac Brand Only)
11
8307002
2
Lockwasher, 1/4 (Velvac Brand Only)
12
8303697
2
Screw, Round Hd Machine, Type B, 3/8 x 3/4
13
8310077
1
Nut, Jam, M5
14
8223216
1
Switch, Transmission Temperature
15
8223510
1
Sender, Low Oil Pressure
16
8223217
1
Sender, Water Temperature
18
8277143
1
Relay, Starter
19
8270416
1
Starter (Includes Solenoid)
20
8584001
3
Tie Wrap (Not Shown)
21
8270219
1
Alternator (Delco)
8270221
1
Alternator (Bosch)
22
8033341
1
Fan, Alternator (Motorola or Prestolite alternator only)
23
7070992
1
Sender, Fuel Level
24
8310078
1
Lockwasher, M5
25
8305201
1
Nut, Hex, Brass, #8-32
26
8310041
1
Lockwasher, External Tooth, #8
27
8220073
1
Terminal, Slip-On Male, #10 SCR
28
8033406
1
Solenoid, Fuel Run, 12 Volt
29
8307023
1
Lockwasher, M10
30
8305438
1
Nut, Jam, M10
31
8307022
2
Lockwasher, M8
32
8305043
2
Nut, Hex, M8
KITS
33
7098881
1
Wire Harness Kit (For Machines with Delco Alternator)
7098871
1
Wire Assembly
7098864
1
Wire Harness (Bosch)
Part Number
Qty.
Description
Item
No.
7.4
Revised 11/97
ELECTRICAL SYSTEM - ENGINE HARNESS
(S/N 9B0501 & AFTER - CUMMINS ENGINE)
