SkyTrak 6036 Parts Manual - Manual (Page 271)

6036
9.9
Part Number Qty. Description
Item
No.
1 7077344 1 Carriage, Side Tilt - 48" (Includes Itmes 3 thru 5)
2 7077444 1 Carrige, Side Tilt - 60" (Includes Items 3 thru 5)
3 7065482 2 Pad Wear
4 8303739 2 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
5 8305626 2 Locknut, 5/16-18
6 7086894 1 Base, Pivot
7 7077501 1 Pin, Cylinder Base
8 7077511 1 Pin, Cylinder Rod
9 7077481 2 Spacer
10 8065643 1 Bushing, Self Align
11 8642001 1 Ring, Snap
12 8642235 4 Ring, Snap
13 8760117 2 Connector, Straight, SAE 6-6 - male JIC° x amle str. thd. O-ring
14 8584001 1 Tie Wrap
15 2711992 2 Hose Assembly
16 8760030 2 Connector, Straight, SAE 6-6P - male JIC° x male NPT
17 8420056 1 Quick Disconnect, Male 6/6" NPT
18 8420057 1 Quick Disconnect, Female 6/6" NPT (Includes Item 18A)
18A 8640027 1 O-Ring, Viton for High Temp. Application of Item 18
19 8541433 1 Plug, Pipe Hex, Socket, 1/8
20 8420058 1 Cap, Dust, SAE 6
21 8420059 1 Plug, Dust, SAE 6
22 8582406-0090 1 Moulding
23 7080231 1 Pin, Pivot
24 8642207 2 Ring, Snap
25 7075942 1 Shaft, Fork Pivot, 48 x 2.75"
26 7075952 1 Shaft, Fork Pivot, 60 x 2.75" (Not Shown)
27 7079251 2 Collar, Locking
28 8303629 2 Screw, Hex Hd Cap, 1/2-13 x 4-1/2
29 8305644 2 Locknut, 1/2-13
30 7069093 2 Fork, Pallet, 48 x 4 x 1.75" (3000 lb Rating)
7077333 2 Fork, Lumber 60 x 7 (Not Shown)
7070623 6 Fork, Blocking (Not Shown)
KITS
31 7096712 1 Conversion Kit, Attachment, Size 6 to Size 8 Quick Couplers
(Includes Items 17, 18, 19, 21 & 22, Page 9.9.3 &
P/N 8760341elbow for Auger Mount to replace corresponding
parts on these attachments)
Revised 11/97
SIDE TILT CARRIAGE - OPTIONAL
PIVOT PIN WITH SNAP RINGS (S/N 9B0472 & BEFORE)
