Cab heater 2.12 – SkyTrak 6036 Parts Manual User Manual
Page 43
6036
HI
OF
F
LO
1
8360008
1
Heater (Includes Items 2 and 3)
2
2
Screw, Hex Hd Cap, 1/4-20 x 1/2
3
4
Lockwasher, 1/4
4
8223024
1
Switch Kit
5
8580309
1
Cap
6
8303615
2
Screw, Hex Hd Cap, 1/4-20 x 1-1/4
7
7772035-0008
2
Spacer, 3/4
8
8221022-0600
2
Conduit, 1/4 ID x 5 Ft. - Cut to Fit
9
8405007
4
Clamp
10
8401012-1340
2
Hose
11
8420201
1
Hose Fitting, Low Pressure, Barbed, SAE 10-8P - hose size 10 x male NPT
12
8540231
1
Elbow, Street, 45° 1/2 NPT
13
8540023
1
Bushing, Hex, 1/2 NPT x 3/8 NPT
14
8360005
1
Valve, Shutoff
15
8584001
4
Tie Wrap
16
8220008
1
Terminal, #10
Item
No.
Part Number
Qty.
Description
CAB HEATER
2.12
Revised 9/94
PA0144
1
7
8
9
2
3
16
4
10
3
6
12
11
9
13
15
14
9
5
CONNECT TO
10 AMP
CIRCUIT
BREAKER
