6036
5.8.2
Part Number
Qty.
Description
Item
No.
1
8585145
2
Plastic Tape, 3/4 x 12
2
2712922
2
Hose Assembly
3
8303786
2
Screw, Hex Hd Cap, 5/16-18 x 2-1/4
4
8769126
3
Clamp Set, Single (2 halves, 1/2 ID)
5
8303743
4
Screw, Hex Hd Cap, 1/4-20 x 1-1/2 (Existing part shown on Page 5.4.2)
6
8769153
2
Plate, Cover (Existing part shown on Page 5.4.2)
7
8769152
2
Clamp Set, Single (2 halves, 3/4 ID) (Existing part shown on Page 5.4.2)
7A
8769152
2
Clamp Set, Single (2 halves, 3/4 ID)
8
8769155
4
Bolt, Stacking
9
8769156
2
Plate, Stacking
10
7084683
2
Tube Assembly
11
8760045
2
Union, Bulkhead, Straight, SAE 8 - male JIC 37°
12
2712582
2
Hose Assembly
13
8584002
1
Tie Wrap
14
8305626
1
Locknut, 5/16-18
15
8769128
2
Plate, Cover
16
8769139
1
Clamp Set, Single (2 halves, 3/4 ID)
16A
8769139
1
Clamp Set, Single (2 halves, 3/4 ID)
17
8310081
1
Screw, Hex Hd Cap, 5/16-18 x 5
18
8760143
1
Connector, Long, SAE 8-8 - male JIC 37° x male str. thd. O-ring
19
8760107
1
Connector, SAE #8 - JIC #8
20
8430005
1
Quick Disconnect, Female 3/4-16 ORB (Includes Items 20A & 20B)
20A
8640029
1
Seal, Nose (Not shown)
20B
8640028
1
Seal, Coupler Body (Not shown)
21
8420055
1
Plug, Dust, SAE 8
22
8430006
1
Quick Disconnect, Male 3/4-16 ORB (Includes Item 22A)
22A
8420029
1
Seal, Nose (Not shown)
23
8420053
1
Cap, Dust, SAE 8
24
8760142
2
Connector, Swivel Nut, SAE 8-8
25
8760045
2
Union, Bulkhead, Straight, SAE 8 - male JIC 37°
26
5713331
4
Washer, Flat (Part of Retrofit Quick Coupler Kit 7096862 - Not used on original
installations)
Revised 11/97
AUXILIARY HYDRAULIC CIRCUIT - OPTIONAL
(S/N 6036-1317 & AFTER)
