SkyTrak 6036 Parts Manual - Manual (Page 73)

6036
3.10
PARK LOCK
Part Number Qty. Description
Item
No.
8033487 1 Park Lock Assembly (Includes Items 1 thru 24)
1 8033166 4 Screw, Socket Hd Cap
2 8033167 1 Plate, Cover
3 8033168 1 Spline, Outer
4 8033169 12 Spring, Red
5 See Kits 1 Plate, Pressure
6 See Kits 1 Plate, Spring
7 See Kits 4 Screw, Socket Hd Cap
8 See Kits 7 Disc, Rotor
9 See Kits 7 Disc, Stator
10 See Kits 1 Disc, Primary
11 See Kits 4 Bolt, Shoulder, Socket Hd
12 See Kits 1 Screw, Bleeder
13 See Kits 1 Ring, Retainer
14 See Kits 1 Bearing
15 See Kits 1 Ring, Retainer
16 See Kits 1 Seal, Oil
17 See Kits 1 Seal, Oil
18 See Kits 2 Seal, Case
19 See Kits 1 Piston
20 See Kits 1 Ring, Backup
21 See Kits 1 Ring, Backup
22 See Kits 1 O-Ring
23 See Kits 1 O-Ring
24 See Kits 1 Nut, Pinion
Kits
25 8033480 1 Pressure & Spring Plate (Includes Items 5, 6, 7 & 24)
26 8033481 1 Disc & Plate Kit (Includes Items 8, 9, 10, 11, 12 & 24)
27 8033482 1 Bearing & Ring Kit (Includes Items 13, 14, 15 & 24)
28 8033483 1 Seal Kit (Includes Items 16, 17, 18 & 24)
29 8033484 1 Piston & Ring Kit (Includes Items 19, 20, 21, 22, 23 & 24)
Revised 11/97
