6036
MAIN CONTROL VALVE CIRCUIT
(S/N 0E1180 AND AFTER w/CABLE CONTROLLED JOYSTICK)
Part Number Qty. Description
Item
No.
1 8401004-0470 1 Hose, Inlet
2 8405209 2 Clamp, Hose,
3 8424222 1 Elbow, Tube, 45°, Barbed, SAE 32 - hose 2 "ID x 4 bolt O-ring
4 8303626 4 Screw, Hex Hd Cap,1/2-13 x 1-1/2
5 8307007 6 Washer, Lock, 1/2
6 7054902 1 Gasket
7 8303602 2 Screw, Hex Hd Cap,1/2-13 x 1-1/4
8 8760107 1 Connector, Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
9 2711832 1 Hose Assembly, Large Pump Outlet
10 8760325 1 Elbow, 90° SAE 12-16 - male JIC 37° x male str. thd. O-ring
11 6604862 1 Hose Assembly, Small Pump Outlet
12 8760015 1 Connector, Straight, SAE 8-8P - male JIC 37° x male NPT
13 8760005 1 Connector, Straight, SAE 16-16P - male JIC 37° x male NPT
14 2711902 1 Hose Assembly, Main Control Valve to Reservoir
15 8303713 3 Screw, Hex Hd Cap, 1/2-13 x 2-1/4 Gr 5
16 8307112 3 Washer, Flat, SAE 1/2
17 8305644 3 Locknut, 1/2-13
18 8640208 1 O-Ring #228
19 8546407 2 Clamp Half 2"
20 8760545 1 Reducer, SAE 16-8 - male str. thd. O-ring x female internal O-ring boss
21 2712342 1 Hose Assembly, Reservoir Return
22 8760109 1 Connector, Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring
23 8760102 1 Connector, Straight SAE 16-16 - male JIC 37° x male str. thd. O-ring
24 8760108 1 Connector, Straight, SAE 8-10 - male JIC 37° x male str. thd. O-ring
Revised 9/94
5.2.4
