6036
1
7098864
1
Harness, Engine
7096874
1
Harness, Engine (Obsolete)
2
8270014
2
Battery, 12 Volt
3
7084542
1
Cable, Battery - Negative
3A
7068651
1
Cable, Starter Ground (Not used with Cable 7084542) (Not Shown)
4
7080192
1
Cable, Battery - Positive
5
8310202
1
Screw, Washer Hd, Type B, 3/8 x 3/4
6
8270602
1
Horn
7
7093442
1
Backup Alarm, Retrofit for ECCO Brand (Includes Hardware)
8270617
1
Alarm, Backup - Velvac Brand Replacement
8
8303615
2
Screw, Hex Hd Cap, 1/4-20 x 1-1/4 Gr 5 (Velvac Brand Only)
9
8305004
2
Nut, Hex, 1/4-20 (Velvac Brand Only)
10
8307002
2
Lockwasher, 1/4 (Velvac Brand Only)
11
8223216
1
Switch, Transmission Temperature
12
8468026
1
Sender, Low Oil Pressure
13
8223217
1
Sender, Water Temperature
14
8274401
1
Solenoid, Fuel Run
15
8032677
1
Switch, Neutral Start
16
8277143
1
Relay, Starter
17
8270411
1
Starter
18
8270412
1
Solenoid, Solenoid
19
8270219
1
Alternator (Delco)
8270221
1
Alternator (Bosch)
20
7070992
1
Sender, Fuel Level
21
7082261
1
Wire Assembly (Not used with Harness 7098864)
22
8277095
1
Plug, Thermo Stat
23
8303987
2
Screw, Round Hd Machine, #8-32 x 1/4
24
8584001
3
Tie Wrap (Not Shown)
25
8305438
1
Nut, Jam, M10
26
8307022
2
Lockwasher, M8
27
8305043
2
Nut, Hex, M8
28
8310078
1
Lockwasher, M5
KITS
29
7098881
1
Wire Harness Kit (For Machines with Delco Alternator)
7098871
1
Wire Assembly
7098864
1
Wire Harness (Bosch)
Part Number
Qty.
Description
Item
No.
7.3
PA0613
ELECTRICAL SYSTEM - ENGINE HARNESS
(S/N 9B0501 & AFTER - PERKINS ENGINE)
Revised 11/97
