Page 53
6036
1
8032500
1
Gasket, Charging Pump
2
8032501
3
O-Ring
3
8032502
1
Charging Pump Assembly
4
8032503
27
Lockwasher
5
8032504
1
Screw, Pump Mounting
6
8032505
2
Screw, Pump Mounting
7
8032506
2
Nut, Stud
8
8320254
1
Filter Assembly
9
8032508
3
Plug, Pipe
10
8032509
1
Breather
11
8032510
1
Stud, Pump Mounting
12
8032511
1
Stud, Pump Mounting
13
8032512
1
Housing, Converter
14
8032513
1
Tube Assembly, Dipstick
15
8032514
1
Dipstick
16
8032515
2
Plug, Pipe
17
8032516
2
Plug, Pipe
18
8032517
1
Sleeve, Converter Housing
19
8032541
2
Screw, Bearing Support
19A
8307005
2
Lockwasher
20
8032542
1
Support, Bearing
21
8032543
1
Ring, Retaining
22
8033199
1
Bearing
23
8032545
1
Ring, Locating
24
8032546
1
Gear, Pump Drive
25
8032518
1
Screen Assembly
26
8032519
1
Gasket, Screen
27
8032520
22
Screw, Housing to Case
28
8032521
3
Pin, Dowel
29
8032523
3
O-Ring
30
8032569
1
Rear Cover and Plug Assembly (Includes Item 31)
31
8032516
1
Plug, Pipe
32
8032503
9
Lockwasher
33
8032524
9
Screw, Rear Cover to Case
34
8032525
1
Bearing Cap Assembly, Rear, Low Shaft (Includes Item 35)
35
8032526
1
Plug
36
8032527
1
Gasket, Rear Cover to Case
37
8032537
1
Gasket, Converter Housing to Case
38
8032539
1
Plug, Pipe
39
8032528
2
Plug, Magnetic Drain
40
8032540
1
Case Assembly, Transmission (Includes Items 41 thru 50)
41
8032522
2
Sleeve, Tube
42
8032529
1
Tube, Clutch Lube
43
8032530
1
Baffle, Oil
44
8032531
2
Seal, Oil Baffle
45
8032532
1
O-Ring
46
8032533
1
Tube Assembly. Suction
47
8033307
1
Sleeve, Tube
48
8032535
2
Lockwasher
49
8032536
2
Screw
50
8032538
1
Tube, Low Speed Clutch Pressure
CONVERTER AND TRANSMISSION HOUSINGS
Revised 9/94
3.1
Item
Part Number
Qty.
Description
No.
