ENGINE RADIATOR AND OIL COOLER MOUNTING
(CUMMINS 4BT3.9 - TURBO - S/N 6036-1525 AND BEFORE)
Part Number
Qty.
Description
Item
No.
1
8262127
1
Engine, Cummins 4B3.9 Turbo
2
7088413
1
Mount, Engine
3
8303640
1
Screw, Hex Hd Cap, 3/4-10 x 3.25
4
8278007
1
Mount, Vibration
5
7054351
1
Washer, Rebound
6
8310067
1
Locknut, 3/4-10 ESNA
7
8303790
10
Screw, Hex Hd Cap, M12 x 30MM
8
8307025
10
Lockwasher, M12
9
8305624
6
Locknut, 1/4-20
10
8307202
14
Washer, Flat, 1/4
11
7085422
1
Tank, Radiator Overflow (Includes Item 11A)
11A
8866341
1
Cap w/tether
12
8406103
1
Support, Hose, 0.62
13
7093803
1
Radiator (Includes Item 14)
14
8180306
1
Cap, Radiator
15
7088314
1
Hose, Radiator, Upper
16
7088322
1
Hose, Radiator, Lower
17
8405104
4
Clamp, Hose, 2.25
18
8405203
2
Clamp, Hose, 3.0
19
8904001
1
Draincock, 1/4
20
8305645
11
Locknut, 3/8-16
21
7057141
3
Wahser, Rebound
22
8278008
3
Mount, Vibration
23
7088303
1
Shroud, Radiator
24
8307002
8
Washer, Lock 1/4
25
8303705
10
Screw, Hex Hd Cap, 1/4-20 x 0.75
26
7088372
1
Support, Radiator
27
8303622
1
Screw, Hex Hd Cap, 3/8-16 x 2.0
28
7091973
1
Crossmember, Rear Frame
29
8303621
8
Screw, Hex Hd Cap, 3/8-16 x 1.5
30
8303686
10
Screw, Hex Hd Cap, 3/4-10 x 2.50
31
8305017
10
Nut, Hex, 3/4-10
32
8307010
10
Lockwasher, 3/4
33
7083982
2
Support, Oil Cooler
34
8307204
4
Washer, Flat, 3/8
35
8320253
1
Element, Fuel Filter - Primary
36
8320250
1
Element, Fuel Filter - Secondary
37
8080613
1
Belt, Fan
38
8270220
1
Fan, Alternator (Not Shown)
39
See Item 39A
1
Alternator (Motorola or Prestolite Type)
39A
8270219
1
Alternator (Delco Type)
8270221
1
Alternator (Bosch Type)
40
8033342
1
Pulley, Alternator
41
8272009
1
Fan, Cooling 17" Puller
42
8270416
1
Starter
43
8277143
1
Relay, Starter
44
7082452
1
Bracket, Starter Relay
45
7088352
1
Kit, Engine Coolant Heater (Option)
46
8320262
1
Element, Engine Oil Filter
47
8403223
1
Cap, Test
48
8307222
4
Washer, Flat, M8
49
8310028
4
Screw,Hex Hd Cap, M8 x 70MM
Kits
50
7098461
1
Kit, Radiator Connection (Includes one of each Items 17 & 47)
