Differntial carrier assembly - front axle 3.11 – SkyTrak 6036 Parts Manual User Manual
Page 75
6036
DIFFERNTIAL CARRIER ASSEMBLY - FRONT AXLE
3.11
Part Number
Qty.
Description
Item
No.
1
8032817
1
Differential Carrier Assembly (Includes Items 2 thru 40)
2
8032834
2
Ring, Adjusting
3
8032836
2
Cup, Roller Bearing
4
8032835
2
Cone, Roller Bearing
5
8032830
12
Screw, Differential
6
8032821
1
Differential Case Assembly (Includes Items 7 thru 13)
7
8032828
2
Washer, Thrust
8
8032824
2
Gear, Differentail Side
9
8032823
2
Washer, Pinion Thrust
10
8032827
2
Gear, Pinion
11
8032822
1
Shaft, Differential
12
8032825
1
Case, Differentail
13
8032829
1
Pin, Pinion Bearing Cage
14
8032837
1
Gear & Pinion Assembly
15
8032838
1
Cone, Roller Bearing
16
8032839
1
Cup, Roller Bearing
17
8032840
AR
Shim, Bevel Pinion Bearing, 0.003
18
8032841
AR
Shim, Bevel Pinion Bearing, 0.005
19
8032842
AR
Shim, Bevel Pinion Bearing, 0.010
20
8032954
1
Carrier Assembly (Includes Items 21 thru 24)
21
N.S.S
1 Carrier
22
N.S.S
2 Cap, Differential Carrier
23
8032819
4
Screw, Differential Bearing Cap
24
8032820
4
Washer, Differential Bearing Cap
25
8032831
2
Bolt, Hex
26
8032832
2
Washer, Flat
27
8032833
2
Clip, Adjusting Ring
28
8033824
14
Screw, Cap, Hex Hd
29
8032855
14
Washer, Flat
30
8032843
1
Spacer, Flat
31
8033807
AR
Shim, Adjusting
32
8032845
1
Cup, Roller Bearing
33
8032846
1
Cone, Roller Bearing
34
8032847
1
Washer, Thrust, Bearing
35
8032980
1
Seal, Oil (See Kits)
36
8032849
1
End Yoke Assembly (Includes Items 37 & 38)
37
8032850
1
Deflector
38
8032960
1
End Yoke
39
8032851
1
Wahser, Pinion Nut
40
8032852
1
Nut, Pinion (See Kits)
41
8033179
1
Housing, Axle
42
8032859
2
Fitting, Grease
43
7089722
2
Bushing, Axle Pivot
44
8032857
2
Pin, Dowel
45
8032854
2
Plug, Pipe
46
8033228
1
Vent
Kits
47
8033485
1
Front or Rear Axle Seal Kit - w/Brakes (Includes the following items which
contains enough seals to service one complete axle)
Oil Seal, Pinion (Item 35, Page 3.11)
Nut, Pinion (Item 40, Page 3.11)
Oil Seal, Deflector (Item 9, Page 3.13
Oil Seal, Shaft/Housing (Item 10, Page 3.13)
Oil Seal, King Pin (Item 22, Page 3.13)
Oil Seal, Wheel Hub (Item 40, Page 3.15)
Oil Seal, Shaft Spindle (Item 42, Page 3.15)
Revised 11/97
