SkyTrak 6036 Parts Manual - Manual (Page 147)

6036
Item
No.
Part Number Qty. Description
5.3
Revised 9/94
BOOM RAISE/LOWER & EXTEND/RETRACT CIRCUITS
(S/N 9B0499 AND BEFORE)
1 2711862 2 Hose Assembly, Extend Cylinder
2 7081843 1 Tube Assembly
3 7081833 1 Tube Assembly
4 8760037 2 Union, Bulkhead, Straight, SAE 10 - male JIC 37°
5 2711852 2 Hose Assembly, Right Hoist Cylinder
6 8760305 4 Elbow, 90° SAE 12-12 - male str. thd. O-ring
7 2712132 1 Hose Assembly, Left Hoist Cylinder Rod
8 2712152 1 Hose Assembly, Left Hoist Cylinder Base
9 8760101 2 Connector, Straight, SAE 10-12 - male JIC 37° x male str. thd. O-ring
10 8760535 2 Reducer, SAE 12-8 - male str. thd. O-ring female internal O-ring boss
11 8760510 2 Tee, Male Run, SAE 8-8 - male JIC 37° x male str. thd. O-ring
12 8584002 4 Tie Wrap (Not Shown)
13 8769127 1 Clamp Set, 1" ID - 2 Halves
14 8769128 2 Plate, Cover
15 8760304 2 Elbow, 90° SAE 10-10 - male JIC 37° x male str. thd. O-ring
16 8303752 1 Scerw, Hex Hd Cap, 5/16-18 x 3-1/2
17 8305626 1 Locknut, 5/16-18
