6036
Part Number Qty. Description
Item
No.
Revised 9/94
5.3.1
BOOM RAISE/LOWER & EXTEND/RETRACT CIRCUITS
(S/N 9B500 & AFTER w/ELECTRONIC CONTROLLED
JOYSTICK)
1 2711862 2 Hose Assembly, Extend Cylinder
2 7081833 1 Tube Assembly
3 7081843 1 Tube Assembly
4 8760037 2 Union, Bulkhead, Straight, SAE 10 - male JIC 37°
5 2711852 2 Hose Assembly, Right Hoist Cylinder
6 8760109 4 Connector, Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring
(Benton Harbor Cyl. Only)
6A 8760254 4 Elbow, 90° SAE 12-12 - male JIC 37° x female JIC 37° swivel
(Benton Harbor Cyl. Onyl)
6B 8760305 4 Elbow, 90° SAE 12-12 - male JIC 37° x female JIC 37° O-ring
(T.J Brooks Cyl. Onyl)
7 2712132 1 Hose Assembly, Left Hoist Cylinder Rod
8 2712152 1 Hose Assembly, Left Hoist Cylinder Base
9 8760535 2 Reducer, SAE 12-8 - male str. thd. O-ring x female internal O-ring boss
10 8760510 2 Tee, Male Run, SAE 8-8 - male JIC 37° x male str. thd O-ring
11 8584002 3 Tie Wrap
12 8769127 1 Clamp Set, 1" ID - 2 Halves
13 8769128 2 Plate, Cover
14 8303752 1 Screw, Hex Hd Cap, 5/16-18 x 3-1/2
15 8305626 1 Locknut, 5/16-18
16 8760304 2 Elbow, 90° SAE 10-10 - male JIC 37° x male str. thd. O-ring
17 8760101 2 Connector, Straight, SAE 10-12 - male JIC 37° x male str. thd. O-ring
18 8760550 1 Reducer, SAE 10-12 - male str. thd. O-ring x female internal O-ring boss
19 8760481 1 Tee, Male Run, SAE 10-10 - male JIC 37° x male str. thd O-ring
20 8760486 1 Reducer, SAE 10-8 - male JIC 37° x male str. thd. O-ring
21 88760142 1 Connector, Straight, SAE 8-8 - male str. thd. O-ring x female JIC 37° swivel
22 7089292 1 Tube Assembly, 1/2 O.D.
23 8760303 1 Elbow, 90° SAE 8-8 - male JIC 37° x male str. thd. O-ring
24 8760533 1 Reducer, SAE 16-8 - feamle JIC 37° x male JIC 37°
25 8902655 1 Valve, Relief (Set at 2850 psi ± 50 psi)
