6036
CONVERTER GROUP
(CLARK MODEL 12.2 HR18306-42 ONLY)
Revised 9/94
1
8032541
2
Screw, Bearing Support
2
8032545
1
Ring, Locating
3
8032542
1
Support, Bearing
4
8032550
1
Ring, Retaining
5
8032551
1
Bearing
6
8032545
1
Ring, Locating
7
8032552
1
Gear, Pump Drive
8
8032545
1
Ring, Locating
9
8032543
1
Ring, Retaining
10
8032553
1
Gear, Idler
11
8033199
1
Bearing
12
8032543
1
Ring, Retaining
13
8032545
1
Ring, Locating
14
8032554
1
Ball, Lock
15
8032555
1
Shaft, Idler Gear Stub
16
8032556
1
Baffle Assembly, Oil
17
8032557
1
Seal, Oil
18
8032558
1
Ring, Piston
19
8032559
1
Spring, Piston Ring Expander
20
8032560
1
Support, Stator
21
8307005
6
Lockwasher
22
8303620
6
Screw
23
8032563
1
Ring, Snap
24
8032564
1
Ring, Piston
25
8032565
1
Ring, Retaining
26
8032566
1
Washer, Locating
27
8032567
1
Bearing, Turbine Shaft
28
8032568
1
Turbine Shaft Assembly (Includes Item 29)
29
8032620
1
Ring, Retaining
30
8032570
3
Screw, Bearing Retaining Plate
31
8032571
1
Plate, Lock
32
8032572
1
Plate, Retaining
33
8032573
1
Gear, Reverse Idler
34
8032574
1
Bearing Assembly
35
8032575
1
Shaft, Reverse Idler
36
8032576
1
Pin, Shaft
37
8032503
3
Washer, Lock
38
8032577
3
Screw
39
8032578
1
Ring, Retaining
40
8032579
1
Reaction Member
41
8032580
1
Spacer
42
8032581
8
Screw
43
8032582
4
Lock Tab
44
8032583
1
Impeller
45
8032584
1
O-Ring
46
8032585
1
Gear, Impeller Hub
47
8032586
1
Bearing
48
8032587
1
Ring, Retaining
49
8032588
1
Hub, Turbine
50
8032589
1
Turbine
51
8032590
12
Washer
52
8032591
12
Screw
53
8032592
1
Ring, Locating
54
8032593
1
Bearing
55
8032594
1
Washer
56
8032595
1
O-Ring
57
8032596
1
Impeller Cover (Includes Item 58)
58
8032600
1
Ring, Retaining
59
8303620
24
Screw
60
8032587
1
Ring, Retaining
61
8032598
1
O-Ring
62
8032599
1
Plug, Bore
63
8032601
1
Drive Plate Assembly Kit (Includes Items 64, 65 and 66)
64
N.S.S.
1
Drive Plate
65
8032602
1
Ring, Backing
66
8032603
10
Screw
67
8307005
36
Lockwasher
3.2
Item
Part Number
Qty.
Description
No.
