6036
Part Number Qty. Description
Item
No.
1 8032666 9 Screw
2 8037005 9 Lockwasher
3 8033239 1 Valve Assembly, Control (w/Declutch) (Includes Items 4 thru 7 and item 16)
4 8032672 1 Spool, Valve
5 8032673 1 Spring, Control Valve
6 8032676 1 Stop, Valve Spool
7 8032679 1 Housing Assembly, Control Valve (Includes Items 8 thru 15)
8 8032674 1 Spool, Forward and Reverse Valve
9 8032675 2 Seal, Oil
10 8032677 1 Switch, Neutral
11 8032678 1 Pin, Switch Actuating
12 8032680 3 Plug, Pipe
13 8032682 1 Spool and Plug Assembly, Speed Selector (Includes Item 14)
14 8032681 1 Plug
15 8032676 2 Stop, Valve Spool
16 8841314 1 Actuator Assembly, Hydraulic (Includes Items 17 thru 21)
17 8033202 1 O-Ring, Piston Housing
18 8033203 1 Kit, Balance Spring and Pin
19 8033204 1 Seal, Piston
20 8033205 1 Piston
21 8033238 1 Glyd Ring Assembly
22 8032668 1 Gasket, Control Valve
23 8032669 2 Ball, Detent
24 8032670 2 Sprin, Detent
25 8303987 2 Screw, Slotted Pan Head, 8-32 x 1/4
3.5.1
Revised 11/97
CONTROL VALVE ASSEMBLY
(S/N 0E1180 AND AFTER)
