6036
5.10
Part Number Qty. Description
Item
No.
HYDRAULIC OIL COOLING CIRCUIT - OPTIONAL
(S/N 6036-1525 AND BEFORE)
1 5715112 1 Oil Cooler
2 8303620 4 Screw, Hex Hd Cap, 3/8-16 x 1
3 8307204 4 Washer, Flat, 3/8
4 8305645 6 Locknut, 3/8-16 ESNA
5 2712082 2 Hose Assembly, 60"
6 6604902 2 Hose Assembly, 105"
7 8760008 2 Union, SAE 12 - male JIC 37°
8 8760109 1 Connector, Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring (Used on
newer reservoirs with straight fitting)
8760020 1 Connector, Straight, SAE 12-8P - male JIC 37° x male NPT (Used on
older reservoirs with tapered pipe fitting)
9 8760112 1 Connector, Straight, SAE 12-10 - male JIC 37° x male str. thd. O-ring
10 8760305 3 Elbow, 90° SAE 12-12 - male JIC 37° x male str. thd. O-ring
11 8760317 1 Elbow, Elbow, 45° SAE 12-12 - male JIC 37° x male str. thd. O-ring
12 7097811 1 Support, Hose
13 7098271 1 Tee, Swivel Run, SAE 12 male with SAE 8 female port
14 8223217 1 Switch, Temperature, SAE 8 NPT, 210°
15 7098281 1 Wire Assembly, 80"
16 8220060 1 Adapter, Blade Terminal
17 8303675 2 Screw, Hex Hd Cap, 3/8-16 x 1-1/4
18 7097751 1 Support, Upper Cooler
19 7097761 1 Support, Lower Cooler
NOTE: The following parts are used on the hydraulic oil cooling circuit, Page
5.7, and are shown for reference.
20 2712082 1 Hose Assembly, 60 "
21 2712102 1 Hose Assembly, 77 "
22 8760109 3 Connector, Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring
23 8760305 1 Elbow, 90° SAE 12-12 - male JIC 37° x male str. thd. O-ring
24 5715112 1 Oil Cooler
Origin 9/94
