SkyTrak 6036 Parts Manual - Manual (Page 141)

6036
Part Number Qty. Description
Item
No.
Revised 9/94
MAIN CONTROL VALVE CIRCUIT
(S/N 9B0500 THRU 0E1179 w/CABLE CONTROLLED JOYSTICK
1 8424003 1 Hose Fitting, Beaded, SAE 32-32P - hose 2" ID x male NPT
2 8405209 2 Clamp, Hose
3 8401004-0470 1 Hose, Inlet
4 8303626 4 Screw, Hex Hd Cap, 1/2-13 x 1-1/2
5 8307007 6 Washer, Lock, 1/2
6 8424222 1 Hose Fitting, Elbow, Tube, 45° Barbed,SAE 32 - hose 2 " ID x 4 bolt O-ring
7 8546407 2 Clamp Half, 2"
8 8640208 1 O-Ring #228
9 7054902 1 Gasket
10 8303602 2 Screw, Hex Hd Cap,1/2-13 x 1-1/4
11 8760545 1 Reducer, SAE 16-8 - male str. thd. O-ring x female internal O-ring boss
12 8760107 1 Connector, Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
13 6604862 1 Hose Assembly, Small Pump Outlet
14 8760325 1 Elbow, 90° SAE 12-16 - male JIC 37° x male str. thd. O-ring
15 2711832 1 Hose Assembly, Large Pump Outlet
16 8760109 1 Connector, Straight, SAE 12-12 - male JIC 37° x male str. thd. O-ring
17 8760102 1 Connector, Straight, SAE 16-16 - male JIC 37° x male str. thd. O-ring
18 2711902 1 Hose Assembly, Main Control Valve to Filter
19 8760553 1 Tee, Male Run, SAE 16-16P - male JIC 37° x male NPT(See NOTE)
20 8540048 1 Bushing, Hex, 1-1/4 " NPT x 1 " NPT (See NOTE)
21 8760533 1 Reducer, SAE 16-8 - female JIC 37° x male JIC 37° (See NOTE)
22 8303713 3 Screw, Hex Hd Cap, 1/2-13 x 2-1/4 Gr 5
23 8307112 3 Washer, Flat, SAE 1/2
24 8305644 3 Locknut, 1/2-13
25 2712342 1 Hose Assembly, Reservoir Return
26 8760108 1 Connector, Straight, SAE 8-10 - male JIC 37° x male str. thd. O-ring
NOTE: Items 19, 20 and 21 are not used with a converted reservoir. See
Page 6.1.1 for reservoir conversion kit.
