SkyTrak 6036 Parts Manual - Manual (Page 13)

6036
Part Number Qty. Description
Item
No.
OPERATOR'S CAB - OPEN
2.1
1 7112102 1 Cab Assembly, FOPS Orange - (Includes Items 2 thru 8)
7112112 1 Cab Assembly, FOPS White - (Includes Items 2 thru 8)
2 8033050 2 Panel, Lower
3 8303034 16 Screw, Truss Hd Machine, Torx, 1/4-20 x 3/4
4 8033052 1 Panel, Right Front Console
5 8033053 1 Panel, Side Console
6 8033031 1 Gasketing, Sponge Rubber, 25-1/4
7 8033022 1 Cover, Battery S/N 8L0328 & After
7126272 1 Cover, Battery S/N 8L0327 & Before
8 8342807 1 Lock, Cam
9 8033051 1 Panel, Left Front Console
10 8307002 3 Lockwasher, 1/4
11 8307109 3 Washer, Flat, 1/4
12 8466307 1 Gauge, Tilt Angle
13 8721023 1 Column, Steering
14 8307005 10 Lockwasher, 3/8
15 8303534 4 Screw, Flange Hd Cap, 3/8-16 x 1-1/4
16 8720014 1 Wheel, Steering
17 8305916 1 Nut, Steering Column
18 8720015 1 Cap, Steering Wheel
19 8864038 1 Arm Rest
20 8065639 1 Bushing, Sleeve
21 8302147 1 Pin, Roll
22 7098342 1 Bracket, Arm Rest
23 8303705 2 Screw, Flange Hd Cap, 1/4-20 x 3/4
24 8990147 1 Holder, Manual
25 8303729 3 Screw, Hex Hd Cap, 1/4-20 x 5/8
26 8221011-0600 1 Conduit, 1/2 ID x 5' - Cut to fit
27 8304014 3 Bolt, Carriage, 3/8-16 x 9
28 7082971 1 Bar, Battery Hold-down
29 8403217-0080 3 Hose
30 8305645 3 Nut, Lock, 3/8-16
31 8305624 2 Nut, Lock, 1/4-20
32 8310050 1 Screw, Hex Hd Cap, 1-8 x 6
33 8307012 2 Lockwasher, 1"
34 8310049 1 Screw, Hex Hd Cap, 1-8 x 2-3/4
35 8310112 1 Screw, Hex Hd Cap, 3/4 10 x 6
36 8307010 2 Lockwasher, 3/4
37 8303638 1 Screw, Hex Hd Cap, 3/4-10 x 2-3/4
38 8305008 6 Nut, Hex, 3/8-16
39 8310070 4 Retainer, 3/8
40 8310036 4 Bolt, Carriage, 3/8-16 x 1-1/4
41 7097233 1 Guard, Bottom
42 7084882 1 Step
43 8303534 2 HHCS, 3/8-16 x 1-1/4
Revised 11/97
