6036
ELECTRONIC JOYSTICK ASSEMBLY
8224016
1
Joystick Assembly (Includes Items 1 thru 18)
1
8033389
1
Boot
2
8033390
1
Clamp Boot
3
8033391
1
Gasket, Mounting
4
8033392
4
Screw, M5 x 10
5
8033393
4
Washer, Nylon #10
6
8033394
1
Boot, Pushbutton
7
8033395
4
Microswitch
8
8033396
8
Screw, #4-10 x 7/8
9
8033397
4
Insulator Cap
10
8033398
2
Pot Plate Assembly
11
8033399
1
Coupling, Shaft w/Screws
12
8033400
1
Button, Actuating
13
8033401
1
Switch, Pushbutton
14
8033402
1
Gate, Special
15
8033403
1
Stop, Return Spring w/Nut & Lockwasher
16
8033404
1
Handle Section w/Gaskets (Both Halves)
17
8033405
1
Wire, 3 Condcutor, 24" Long
18
8033490
1
Plate, Switch
Part Number
Qty.
Description
Item
No.
Revised 9/94
7.5
