14 fuel system (cummins engines) – SkyTrak 6036 Parts Manual User Manual
Page 129
6036
Part Number
Qty.
Description
Item
No.
1
7127321
1
Tank, Fuel (Includes items 2 thru 7)
2
8033111
1
Cap, Filler, w/tether
3
8033109
1
Elbow, 90° w/standpipe
4
8033175
1
Bushing, Rubber
5
8033176
1
Elbow, 90° w/standpipe
6
8405101
1
Clamp, Hose
7
NSS
1
Tank, Fuel
8
8405009
6
Clamp, Hose
9
8310180
5
Screw, Machine, 10-24 x 3/8
10
8307003
5
Lockwasher, #10
11
7070992
1
Sender, Fuel Level
12
8584001
2
Tie Wrap
13
8403214-1290
1
Hose, Fuel Return, 1/4 x 129.0
14
8403219-1400
1
Hose, Fuel Supply, 5/16 x 140.0
15
8403219-0120
1
Hose, Fuel Supply, 5/16 x 12.0
16
8274021
1
Fuel Pre-Filter All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
8274022
1
Fuel Strainer - Inline - Not Shown (S/N 3617 & After Turbo Charged Only)
17
8303705
2
Screw, Hex Hd Cap, 1/4-20 x 0.75
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
18
8305624
2
Locknut, 1/4-20
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
19
8420231
1
Fitting, Barbed 1/4 NPT x 5/16 T
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
8430007
1
Fitting, Barbed 1/4 NPT x .38 T (S/N 3617 & After Turbo Charged Only)
20
7091291
2
Tube All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
21
8274209
2
Bushing, Hex, 1/2-20 x 5/16 tube
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
22
8274210
2
Sleeve All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
23
7082452
1
Bracket, Fuel Pre-Filter Mounting
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
24
8320250
1
Element, Fuel Filter - Secondary
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
25
8320253
1
Element, Fuel Filter - Primary
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
26
8303790
2
Screw, Hex Hd Cap, M12 x 20 mm
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
27
8307025
2
Lockwasher, M12
All Naturally Aspirated And (Turbo Charged S/N 3616 & Before)
28
8320270
1
Element, Single Filter/ Water Separator
(S/N 3617 & After Turbo Charged Only)
4.14
FUEL SYSTEM
(CUMMINS ENGINES)
Revised 11/97
