6036
Part Number Qty. Description
Item
No.
MAIN CONTROL VALVE CIRCUIT
(S/N 9B0500 THRU 0E1179 w/ ELECTRONIC CONTROLLED JOYSTICK)
5.2.1
Revised 9/94
1 8401004-0470 1 Hose, Inlet
2 8405209 2 Clamp, Hose
3 8424003 1 Hose Fitting, Beaded, SAE 32-32P - hose 2" ID x male NPT
4 8424222 1 Elbow,Tube, 45°, Barbed, SAE 32 - hose 2 "ID x 4 bolt O-ring
5 8303626 4 Screw, Hex Hd Cap,1/2-13 x 1-1/2
6 8307007 6 Washer, Lock,1/2
7 7054902 1 Gasket
8 8303602 2 Screw, Hex Hd Cap,1/2-13 x 1-1/4
9 8760107 1 Connector, Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
10 2711832 1 Hose Assembly, Large Pump Outlet
11 8760325 1 Elbow, 90° SAE 12-16 - male JIC 37° x male str. thd. O-ring
12 6604862 1 Hose Assembly, Small Pump Outlet
13 8540048 1 Bushing, Hex, 1-1/4 " NPT x 1 " NPT (See NOTE)
14 8760553 1 Tee, Male Run, SAE 16-16P - male JIC 37° x male NPT (See NOTE)
15 2711902 1 Hose Assembly, Main Control Valve to Reservoir
16 8760533 1 Reducer, SAE 16-8 - female JIC 37° x male JIC 37° (See NOTE)
17 8303713 3 Screw, Hex Hd Cap, 1/2-13 x 2-1/4 Gr 5
18 8307112 3 Washer, Flat, SAE 1/2
19 8305644 3 Locknut, 1/2-13
20 8640208 1 O-Ring #228
21 8546407 2 Clamp Half 2"
22 8760545 1 Reducer, SAE 16-8 - male str. thd. O-ring x female internal o-ring boss
23 2712342 1 Hose Assembly, Reservoir Return
24 8760118 1 Connector, Straight, SAE 12-16 - male JIC 37° x str. thd. O-ring
25 8760552 1 Tee, Male Branch, SAE 16-16 - male JIC 37° x male str. thd. O-ring
26 8760108 1 Connector, Straight, SAE 8-10 - male JIC 37° x str. thd. O-ring
NOTE: Items 13, 14 and 16 are not used with converted reservoir. See
Page 6.1.1 for reservoir conversion kit.
