Throttle pedal control (cummins engines) – SkyTrak 6036 Parts Manual User Manual
Page 49
6036
Part Number
Qty.
Description
Item
No.
1
8162003
1
Pedal, Throttle (Includes Item 1A)
1A
8033178
1
Bellows, Throttle Pedal
2
8303742
3
Screw, Flange Hd, 1/4-20 x 1-1/4, Gr 5
3
8307002
3
Lockwasher, 1/4
4
8305004
3
Nut, Hex, 1/4-20
5
8160053
1
Cable, Throttle
6
8160610
1
Clamp, Cable
7
8305002
2
Nut, Hex, #10-24
8
8307003
2
Lockwasher, #10
9
8303837
2
Screw, Round Hd, #10-24 x 3/4
10
7088522
1
Bracket, Throttle Cable (Turbo)
7088141
1
Bracket, Throttle Cable (Natural)
11
8301002
1
Clevis, 1/4-28 x 2 (w/pin)
12
8305402
2
Nut, Jam, 1/4-28
13
8307109
3
Washer, Flat, 1/4
14
8305624
2
Locknut, 1/4-20
15
8303705
2
Screw, Flanged Hd, 1/4-20 x .75
16
8302449
1
Pin, Cotter
17
8301402
1
Pin, Yoke
18
8702146
1
Spring, Extension (Natural Only)
19
7097882
1
Bracket, Throttle Spring (Natural Only)
20
8700116
1
Spring, Return
2.14
Revised 11/97
THROTTLE PEDAL CONTROL
(CUMMINS ENGINES)
