SkyTrak 6036 Parts Manual - Manual (Page 279)

6036
9.10
Part Number Qty. Description
Item
No.
1 7111994 1 Carriage - 52"
7110694 1 Carriage - 72"
2 6608621 1 Cover - Clamp
3 8303715 3 Screw, Hex Hd Cap, 5/16-18 x 1-1/2
4 7110702 2 Pin, Carriage Pivot
5 7110494 1 Base Pivot
6 7110712 1 Pin, Cylinder Pivot (Rod End)
7 7110722 2 Pin, Cylinder Pivot (Base End)
8 8307918 AR Shim, 2" ID x 10 Ga
9 8065062 4 Bearing, Self Lube
10 8307904 AR Shim, 2" ID x 18 Ga
11 8310161 AR Shim, 1-1/2" ID x 10 Ga
12 8760113 4 Connector, Straight, SAE 4 - male JIC 37° x male str. thd. O-ring
13 8584001 4 Tie Wrap
14 6604662 2 Hose Assembly
15 8310160 AR Shim, 1-1/2" I.D. x 18 Ga.
16 8430006 1 Quick Disconnect, Male 3/4-16 ORB (Includes Item 17)
17 8640029 1 Seal, Nose (Not Shown)
18 8430005 1 Quick Disconnect, Female 3/4-16 ORB (Includes Items 19, 20 & 20A)
19 8640029 1 Seal, Nose (Not Shown)
20 8640028 1 Seal, Large, Coupler Body (Not Shown)
20A 8640032 1 Back-up Ring for Large Seal (Not Shown)
21 7062922 1 Bearing, Thrust
22 8420053 1 Cap, Dust
23 8420055 1 Plug, Dust
24 8642207 4 Ring, Retaining
25 6611752 2 Hose Assembly
26 8760313 2 Elbow, 90° SAE 6-8 - male JIC° x male str. thd. O-ring
27 8760311 1 Elbow, 90° SAE 6 - male JIC° x male str. thd. O-ring
28 8769132 2 Clamp, Half
29 7112052 1 Shaft, Fork Pivot 52"
7084942 1 Shaft, Fork Pivot 72"
30 7086471 2 Hub, Lock
31 8303634 5 Screw, Hex Hd Cap, 5/8-11 x 4"
32 8305643 5 Locknut, 5/8-11
33 7097523 2 Fork, Pallet 48" x 4" x 2" (4000 lb Rating)
7097533 2 Fork, Lumber (Not Shown)
7085073 6 Fork, Blocking (Not Shown)
34 4107692 2 Chart, Capacity
35 4107702 1 Decal, Danger - Tip Over Hazard
36 8760409 2 Nut, SAE 6 JIC 37°
37 8760475 2 Reducer, Tube End SAE 6-4 JIC 37°
38 8770012 1 Elbow, 90° SAE 6-4 male JIC 37°
39 8770016 1 Reducer, Tube End SAE 4-6
40 4107712 1 Decal, Danger - No Truss Boom
41 8580315 2 Plug, Trim 2-1/2" Dia.
Origin 9/94
SWING CARRIAGE
(OPTIONAL)
