SkyTrak 6036 Parts Manual - Manual (Page 28)

6036
Part Number Qty. Description
Item
No.
BOOM RAISE/LOWER & BOOM EXTEND/ RETRACT CONTROL
(RESISTIVE ELECTRONIC JOYSTICK w/TLC)
2.7.2
Revised 9/94
1 8224016 1 Joystick, Electronic, w/ 50° Gate (See Page 7. 5 for Breakdown)
2 7088533 1 Cover, Console
3 7088232 1 Sensor, Vehicle Attitude
4 7086772 1 Harness, Wire
5 7089712 1 Controller, Electronic
6 7088122 1 Display Unit
7 7088202 1 Horn, Signal
8 7088212 1 Sensor, Boom Length
9 7088222 1 Sensor, Boom Angle
10 7088242 1 Pulley, 0.30 Grooves
11 7088252 1 Pulley, 0.120 Grooves
12 7088262 1 Belt
13 8580313 4 Plug, Trim
14 7088042 1 Bracket, Boom Angle Sensor
15 7088052 1 Bracket, Pulley
16 7088062 1 Cover, Angle Sensor Bracket
17 7088842 1 Bracket, Boom Length Sensor
18 7088653 1 Panel, Lower Front
19 7088081 1 Clamp, Half
20 8769141 1 Clamp, Half
21 8584018 1 Mount, Cable Tie
22 8584002 8 Tie, Plastic
23 8303615 5 Screw, Hex Hd Cap, 1/4-20 x 1.250 Gr 5
24 8307202 17 Washer, Flat, 1/4
25 8307002 15 Lockwasher, 1/4
26 8305004 9 Nut, Hex, 1/4-20
27 8406005 2 Support
28 8769147 2 Clamp,Half
29 8303703 4 Screw, Hex Hd Cap, 1/4-20 x 2.50 Gr 5
30 8303090 2 Screw, Hex Hd Cap, 1/4-20 x 1-1/4 Gr 5
31 7088161 2 Shim, Sensor Bracket
32 8310001 4 Nut, Retainer, 1/4-20
33 8310026 2 Screw, Hex Hd Cap, 1/4-20 x .75 Gr 5
34 8310027 2 Screw, Hex Hd Cap, 1/4-20 x 3.25 Gr 5
35 8305008 3 Nut, Hex, 3/8-16
36 8307204 3 Washer, Flat, 3/8
37 8307005 3 Lockwasher, 3/8
38 8303679 3 Screw, Hex Hd Cap, 3/8-16 x 1.75 Gr 5
39 8220060 1 Adapter
40 8303981 4 Screw, Washer Hd Machine, 10-24 x .50
41 8307003 4 Lockwasher, #10
42 8305002 4 Nut, Hex, #10-24
43 8033034 4 Screw, Truss Hd, Phillips, 1/4-20 x .75 (Black)
44 8303739 1 Screw, Hex Hd Cap, 5/16-18 x 1-1/4 Gr 5
45 8307004 1 Lockwasher, 5/16
46 8305006 1 Nut, Hex 5/16-18
47 8310022 2 Screw, Machine, #4-40 x 3/8
48 8307050 2 Lockwasher, #4
49 8303119 2 Screw, Flange Hex Hd, 1/4-20 x 0.625
50 8584001 1 Tie Wrap
USED ON EARLY MODELS ONLY
51 7090781 1 Conversion Kit, Attitude Sensor Mount (Includes items 52 thru 57)
USED ON LATER MODELS ONLY
52 7090432 1 Bracket, Attitude Sensor Mount
53 7090461 1 Support
54 8310001 2 Nut, Retainer, 1/4-20
55 8310026 2 Screw, Hex Hd Cap, 1/2-20 x 3/4 Gr5
56 8307202 2 Washer, Flat 1/4
57 8307002 2 Lockwasher, #4
