Part number qty. description item no – SkyTrak 6036 Parts Manual User Manual
Page 220
6036
8902146
1
Main Control Valve (Includes Items 1 thru 78)
1
8033255
1
Outlet Section (Includes Items 2 & 3)
2
1
Body, End Cover
3
2
Plug, SAE
4
8033256
1
Tie Rod Kit (Includes Items 5, 6 & 7)
5
4
Rod, Tie
6
4
Nut, Hex
7
4
Nut, Jam
8
8033257
3
Seal Plate Kit (Includes Items 9 thru 15)
9
1
Plate, Seal
10
2
O-Ring
11
1
O-Ring
12
1
O-Ring
13
2
O-Ring
14
1
O-Ring
15
1
Ball, 3/16"
16
8033258
2
Plug, SAE
17
8033278
1
Bypass Compensating Inlet Valve Assembly (Includes Items 16, 18-21, 30, 41-48 & 51)
18
8033279
1
Spool, Bypass
19
8033280
1
Plug, SAE
20
8033281
1
Washer, Spring
21
8033282
1
Spring, Compression
22
8033284
1
Bypass Compensating O-Ring Kit (Includes Items 23 thru 29)
23
1
O-Ring (Not Shown)
24
1
Ring, Backup
25
1
O-Ring
26
1
O-Ring
27
3
O-Ring, Plug (Not Shown)
28
2
O-Ring, Plug (Not Shown)
29
1
O-Ring, Plug (Not Shown)
30
8033285
1
Compensator Adjustment Kit (Includes Items 31 thru 40)
31
1
Seat
32
1
O-Ring
33
1
Ring, Backup
34
1
O-Ring
35
1
Cone, Poppet
36
1
Spring, Pressure Limiter Compression
37
1
Nut, Lock
38
1
Plug, Adjustment
39
1
Screw, Set
40
1
Plug, SAE
41
8033286
1
Screw, Orifice
42
8033287
1
Spool, Pilot Reducing
43
8033288
1
Ball, Valve
44
8033289
1
Guide, Spring
45
8033290
1
Spring, Compression
46
8033291
4
Shim, Pilot
47
8033292
2
Plug,SAE
48
8033295
1
Bypass Pilot Filter Kit (Includes Items 49 & 50)
49
1
O-Ring
50
1
Filter
51
8033293
1
Plug, SAE
52
8033259
1
Hoist Working Section Valve Assembly (Includes Spool)
53
8033260
1
Extend Working Section Valve Assembly (Includes Spool)
54
8033261
1
End Plug Kit (Includes Items 55 thru 60)
55
1
O-Ring
56
1
Ring, Retaining
57
1
Plug
58
1
Plug
59
1
Ring, Retaining
60
1
O-Ring
61
8903009
1
Solenoid Cartridge w/ Weather Pack Connector
62
8033263
1
O-Ring
63
8033264
1
Plug, Compensator
64
8033249
1
Compensator Spring Kit (Includes Items 64A thru 64D)
64A
1
Spring, Compensator
64B
2
Shim, 0.003"
2
Shim, 0.008"
2
Shim, 0.025"
64C
1
Backup Washer
64D
1
Pin, Slotted
Part Number
Qty.
Description
Item
No.
MAIN CONTROL VALVE - ELECTRONIC
(S/N 9B0500 AND AFTER)
6.10.2
Revised 9/94
