Inner boom – SkyTrak 6036 Parts Manual User Manual
Page 263
6036
Part Number
Qty.
Description
Item
No.
1
7116722
1
Inner Boom (S/N 6036-2516 & After)
2
7082362
AR
Shim, Wear Pad, #10 Ga
3
7085442
2
Spacer, Wear Pad
4
7111572
7
Wear Pad
5
7082311
16
Insert, Wear Pad
6
8307005
16
Lockwasher, 3/8
7
8303681
8
Screw, Hex Hd Cap, 3/8-16 x 3/4
8
8303679
6
Screw, Hex Hd Cap, 3/8-16 x 1-3/4
9
8305646
3
Locknut, 3/4-16 ESNA
10
8307104
3
Washer, Flat, 3/4
11
8124126
3
Pin
12
7063472
3
Clevis, Chain
13
8127004
1
Chain, 171 Pitch x 128-1/4
14
8642224
2
Ring, Retaining
15
7081641
1
Pin, Base End, Attachment Tilt Cylinder
16
8520001
2
Fitting, Grease, 1/8NPT
17
7083922
1
Pin, Pivot, Quick Attach
18
8307918
2
Washer, Spacer, 2.0 ID x 3.5 OD
19
8307204
16
Washer, Flat, 3/8
20
8305018
1
Locknut, 3/4-16
21
8642237
6
Ring, Retaining
22
7085542
2
Bushing, Quick Attach Pivot
23
8303738
2
Screw, Hex Hd Cap, 3/8-16 x 7/8
24
7096491
6
Spacer (S/N 6036-2516 & After Only)
25
82210011-0080
1
Conduit, 1/2 x 8
26
7117192
1
Kit, Inner Boom (S/N 6036-2516 & Before)
(Includes Items 27 thru 30 and hose clamps shown on Pages 5.4.2 & 5.8.2
27
7116722
1
Inner Boom w/Bushings (Includes Item 22)
28
8310019
1
Bolt, Shoulder, 1/2" Dia. x 1-1/2"
29
7063482
1
Clevis, Chain
30
8305645
1
Nut, Hex Lock Elastic, 3/8-16
31
7117031
2
Link
9.3
Revised 11/97
INNER BOOM
