Step Procedure
3 For the Balance slider bar controls, see the following.
Click
OK to accept any variance from the default (for this specific slider bar) and return to the Image
Color tab window.
Click
Cancel to negate any variance on the slide and return to the Image Color tab window.
Click Default to clear changes back to the default settings for this window only.
Additional instructions:
Yellow Balance (Default, 0%): Move the slide to the left for (-) or less yellow as an individual color.
Move the slide to the right (+) or more yellow as an individual color balance. Study the image (on the
right) to determine correct color yellow balance effect.
Magenta Balance (Default, 0%): Move the slide to the left for (-) or less magenta as an individual
color. Move the slide to the right (+) or more magenta as an individual color balance. Study the image
(on the right) to determine correct color magenta balance effect.
Cyan Balance (Default, 0%): Move the slide to the left for (-) or less cyan as an individual color
balance. Move the slide to the right (+) or more cyan as an individual color balance. Study the image
(on the right) to determine correct color cyan balance effect.
4 Click Default to clear changes back to the default settings for this window only and NOT for the
Advanced Image Color dialog box.
