1.3 Technical Specifications
Term Description
Print Method Dye Sublimation / Resin Thermal Transfer
Print resolution 300 dpi (11.8 dots/mm); continuous tone
Print Modes There are two print modes (Performance and Normal )
• Normal print mode (default)
• Performance print mode is faster with lower image quality and is
most suitable for minimal color with mostly resin text.
Colors Up to 16.7 million colors / 256 shades per pixel
Accepted Card Types
(Compositions)
ABS, Laminated PVC, PET, PETG, smart cards, mag stripe cards,
optical memory cards, 100% polycarbonate able to accept HDP
retransfer.
Card Cleaning Replaceable cleaning roller (included with each print Ribbon)
Input Hopper Capacity 100 cards , 30 mil cards-standard hopper
200 cards, 30 -40 mil cards- dual-input hopper optional
Output Hopper Card
Capacity
200 card Output Hopper capacity, 30 mil – 40 mil
Reject hopper 5 cards minimum, 30 mil (with flipper module)
Card Sizes (Accepted
Standard sizes)
These Card Printers accept standard CR80 sized cards (3.370L x
2.125W / 85.6mmL x 54mmW) with a thickness of 30 mil to 50 mil
(.030/.762mm).
The Laminator will accept card thickness of 30 mil to 50 mil.
Dual Hopper limited to 30 mil to 40 mil.
Dimensions Printer: 11.50"H x 12.25"W x 9.25"D / 292mmH x 313mmW x 235mmD
Printer + Dual-Sided Module: 11.50"H x 17.50"W x 9.25"D / 292mmH
x 445mmW x 235mmD
Printer + Single-Sided Lam Module: 12.75"H x 25"W x 9.25"D /
324mmH x 635mmW x 235mmD
Printer + Dual-Sided Module + Dual-Sided Lam Module: 12.75"H x
30"W x 9.25"D / 324mmH x 762mmW x 235mmD
Lam Module: 12.75"H x 12.25"W x 9.25"D / 324mmH x 313mmW x
235mmD
Dual Input Hopper: 12” H x 5”W x 5.5” D
Weight Printer : 16 lbs. / 7.3 kg
Printer + Dual-Sided Module: 22 lbs. / 10 kg
Printer + Single-Sided Lam Module: 28 lbs. / 12.7 kg
Printer + Dual-Sided Module + Dual-Sided Lam Module: 36 lbs. /
16.4 kg
Display OLED Graphical Display
