Templates
viewLinc 4.3 4 | 4 57
Single Threshold Template
To create a single-threshold template:
1 From the viewLinc desktop, select Options | System Configuration |
Templates |
Threshold Templates .
2 To modify an existing default High or default Low templates, select
the template and then set the threshold condition as in steps 4 to 6.
3 To create a new template, click Options | Add Single-Threshold
Template (or use the right-click menu). Double-click anywhere in the
title to change it.
4 Set the Threshold conditions:
• Units : Select the Channel’s measurement units.
• Deadband : Specify the measurement range you want
viewLinc to ignore (this range accommodates minor fluc-
tuations which you do not want to trigger an alarm).
• Type : Identify the threshold as a High limit (High or
HighHigh), or Low limit (Low or LowLow), or, indicate the
rate of change in units (ROC Units).
• Value: Enter the threshold limit.
• Category: For reporting purposes, specify whether a Warn-
ing message or an Alarm notification is issued when threshold
condition is met.
• Alarm Template : Choose an existing Alarm Template you
want assigned to the Threshold Template (the Alarm Template
defines how the Threshold Alarm displays, and who is notified
when a Threshold is reached). Choose Private to create custom
Alarm settings you want applied to a single Location to which
you have been granted Access Control permission.
