Discovering Devices
viewLinc 4.3 4 | 4 33
4 Enter the COM port number.
5 Click OK to save.
To add a 300 Series Transmitter:
1 Ensure no other Users are logged on to the Transmitter you want to
add.
2 From the Locations Manager window, on the Devices pane, select
a Host, then select Options | Host |
Add Device .
3 In the Add Device screen, from the Device Class box list, select
300 Series Transmitter
.
4 Enter the following:
• Timeout: To ensure continuous monitoring, do not change
(default 30 seconds).
• Disconnect After Scan: To maintain a persistent connection
to the Device, choose Yes.
• Connection Type: If the transmitter has a LAN or WLAN
module, select Network. If you use an external Digi Device,
choose COM Port.
• IP Address: Enter the IP address.
• Sample Rate : Choose 90 (recommended, but you can modify
the rate if you need more or less recorded data).
5 Click OK to save.
To add an HMT140 Wi-Fi Data Logger:
1 Ensure no other Users are logged on to the HMT140 you want to
add.
2 From the Locations Manager window, on the Devices pane, select
a Host, then select Options | Host |
Add Device .
3 In the Add Device screen, from the Device Class box list, select
HMT140
.
4 Enter the following:
• Timeout: To ensure continuous monitoring, do not change
(default 30 seconds).
• Serial number : Enter the HMT140 serial number.
