Name column displays the Installed icon (

). Please purchase the sufficient capacity before

the license key expires.

• Time Out: The term has already expired for the temporary key. The Product Name column

displays the Not Installed icon (

).

• Reinstall Key: The option is not installed. The Product Name column displays the Not Installed

icon (

).

• Expired: The license key of the option that has been in the Capacity Insufficient status has ex-

pired. The Product Name column displays the Not Installed icon (

).

The Available Install column shows the option that can be installed using the Available button of
Mode in License Install. The row of the option that can be installed using the Available button
shows Enable. For detailed information on installing the option using the Available button, see

Enabling Available XP Remote Web Console Options Automatically

” on page 62.

Table 9 Calculating Volume Capacity

Formula for Calculating Volume Capacity

Volume Emulation Type

712 KB × (number of user cylinders)

3380-x, OPEN-x

848 KB × (number of user cylinders)

3390-x

Table 10 Sample Estimation of Needed Capacity

Value

Item

3390-3

Volume emulation type

3,339

Number of user cylinders

2,048

Number of volumes

870 KB Ч 3,339 Ч 2,048 = 5,949,296,640 kB
5,949,296,640 KB ÷ 1,024 = 5,809,860 MB
5,809,860 MB÷ 1,024 = 5,673.70 GB
5,673.70 GB ÷ 1,024 = 5.54 TB

Total volume capacity

At least 6 TB

Estimated needed capacity

The Total Storage graphic is on the lower left corner of the License Key tab; it displays the total volume
capacity currently available in the array (see

Figure 34

).

Installation Requirements and Procedures

54
