Watlow EZ-ZONE ® RMH Module • 93 • Chapter 4 Setup Page
RM High Density Module • Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[USr;S]
[USr.S] Global
User Settings Save
Save all of this controller's
settings to the selected
set.
[none] None (61)
[SEt1] User Set 1 (101)
[SEt2] User Set 2 (102)
None 26 0x65 (101)
1
0x0E (14)
93 1014 uint
W
[USr;r]
[USr.r] Global
User Settings Restore
Replace all of the control-
ler's settings with another
set previously saved.
[none] None (61)
[SEt1] User Set 1 (101)
[SEt2] User Set 2 (102)
[FCty] Factory (31)
None 24 0x65 (101)
1
0x0D (13)
92 1013 uint
W
[CoM]
[`SEt]
Communications Menu
[bAUd]
[bAUd] Communications
Baud Rate
Set the speed of this con-
troller's communications
to match the speed of the
serial network.
9,600 (188)
19,200 (189)
38,400 (190) 9,600 6504 0x96 (150)
1
3
- - - - 17002 uint
RWE
[`PAr]
[ PAr] Communications
Parity
Set the parity of this con-
troller to match the parity
of the serial network.
[none] None (61)
[EuEn] Even (191)
[`odd] Odd (192)
None 6506 0x96 (150)
1
4
- - - - 17003 uint
RWE
[M;hL]
[M.hL] Communications
Modbus Word Order
Select the word order of
the two 16-bit words in the
floating-point values.
[hiLo] Word High Low
(1330)
[Lohi] Word Low High
(1331)
Low High 6508 0x96 (150)
1
5
- - - - 17043 uint
RWE
[`C_F]
[ C_F] Communications
Display Units
Select which scale to use for
temperature over comms.
°F (30)
°C (15) °F 6510 0x96 (150)
1
6
- - - - 17050 uint
RWE
[`nU;S]
[ nV.S] Communications (1)
Non-volatile Save
If set to Yes all values writ-
ten to the control will be
saved in EEPROM.
Note:
Any value that is changed
from the RUI or over a
communications port will
initiate a write to the EE-
PROM. Life of EEPROM
is approximately one mil-
lion writes.
[`yes] Yes (106)
[``no] No (59)
Yes 6514 0x96 (150)
1
8
198 17051 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E: EEPROM
S: User
Set
