Watlow EZ-ZONE RMH User Manual
Page 56
Watlow EZ-ZONE
®
RMH Module
•
53
•
Chapter 4 Setup Page
RM High Density Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[``Ain]
[ Ain]
Analog Input (1 to 16)
Value
View the process value.
Note:
Ensure that the Error
Status (below) indicates
no error (61) when read-
ing this value using a
field bus protocol. If an
error exists, the last
known value prior to the
error occurring will be
returned.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - -
380
[offset 90]
0x68 (104)
1 to 16
1
0
4001
float
R
[`i;er]
[ i.Er]
Analog Input (1 to 16)
Input Error
View the cause of the most
recent error.
[nonE]
None (61)
[OPEn]
Open (65)
[Shrt]
Shorted (127)
[`E;M]
Measurement Error
(140)
[E;CAL]
Bad Calibration Data
(139)
[Er;Ab]
Ambient Error (9)
[E;;Rtd]
RTD Error (141)
[FAiL]
Fail (32)
[Nsrc]
Not Sourced (246)
None
382
[offset 90]
x68 (104)
1 to 16
2
1
4002
float
R
[``pu]
[`set]
Process Value Menu
[``Fn]
[ Fn]
Process Value (1 to 16)
Function
Set the function that will
be applied to the source or
sources.
[`oFF]
Off (62)
[`S;bA]
Sensor Backup (1201)
[`aug]
Average (1367)
[``C;o]
Crossover (1368)
[`W;b]
Wet Bulb / Dry Bulb
(1369)
[``s;o]
Switch Over (1370)
[diFF]
Differential (1373)
[rAti]
Ratio (1374)
[`add]
Add (1375)
[mul]
Multiply (1376)
[a;dif]
Absolute Difference
(1377)
[min]
Minimum (1378)
[maH]
Maximum (1379)
[root]
Square Root (1380)
[usla]
Vaisala RH Compen-
sation (1648)
[`alt]
Pressure to Altitude
(1649)
Off
8260
[offset 70]
0x7E
(126)
1 to 16
0x15 (21)
98
26021
uint
RWES
[SFn;A]
[SFn.A]
Process Value (1 to 16)
Source Function A
Set the type of function
that will be used for this
source.
[``Ai]
Analog Input (142)
[``Pu]
Process Value (241)
None
8220
[offset 70]
0x7E
(126)
1 to 16
1
- - - -
26001
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E:
EEPROM
S:
User
Set
