Watlow EZ-ZONE ® RMH Module • 45 • Chapter 3 Operations Page
RM High Density Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`CPE]
[oPEr]
Compare Menu
[`Su;A]
[ Su.A] Compare (1 to 24)
Source Value A
View the value of Source
A.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
11272
[offset 40] 0x80
(128)
1 to 24
7
- - - - 28007 float
R
[`Su;b]
[ Su.b] Compare (1 to 24)
Source Value B
View the value of Source
B.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
11274
[offset 40] 0x80
(128)
1 to 24
8
- - - - 28008 float
R
[``o;u]
[ o.v] Compare (1 to 24)
Output Value
View the value of this
function's output.
[`off] Off (62)
[``on] On (63)
11278
[offset 40] 0x80
(128)
1 to 24
0xA (10)
- - - - 28010 uint
R
No Dis-
play
Compare (1 to 24)
Error
Read reported cause for
compare error
None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Cal Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617) 11284
[offset 40] 0x80
(128)
1 to 24
0x0D (13)
- - - - 28013 uint
R
[tMr]
[oPEr]
Timer Menu
[`Su;A]
[ Su.A] Timer (1 to 24)
Value Source A
View the value of Source
A.
[`off] Off (62)
[``on] On (63)
- - - - 13192
[offset 50] 0x83
(131)
1 to 24
7
- - - - 31007 uint
R
[`Su;b]
[ Su.b] Timer (1 to 24)
Value Source B
View the value of Source
B.
[`off] Off (62)
[``on] On (63)
- - - - 13194
[offset 50] 0x83
(131)
1 to 24
8
- - - - 31008 uint
R
[``E;t]
[ E.t] Timer (1 to 24)
Elapsed Time
View the value of this
function's elapsed time.
0 to 30,000.0 seconds 0 13210
[offset 50] 0x83
(131)
1 to 24
0x10 (16)
- - - - 31016 float
R
[``o;u]
[ o.v] Timer (1 to 24)
Output Value
View the value of this
function's output.
[`off] Off (62)
[``on] On (63)
- - - - 13198
[offset 50] 0x83
(131)
1 to 24
0x11 (17)
- - - - 31010 uint
R
No Dis-
play
Timer (1 to 24)
Running
Read to determine if timer
is running
Off (62)
On (63) - - - - 13208
[offset 50] 0x83
(131)
1 to 24
0x0F (15)
- - - - 31015 uint
R
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
