Watlow EZ-ZONE ® RMH Module • 72 • Chapter 4 Setup Page
RM High Density Module • Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[`iP;2]
[ ip.2] Linearization (1 to 24)
Input Point 2
Set the value that will be
mapped to output 2.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
1.0 14396
[offset 70]
0x86 (134)
1 to 24
9
124 34009 float
RWES
[`oP;2]
[ op.2] Linearization (1 to 24)
Output Point 2
Set the value that will be
mapped to input 2.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
1.0 14416
[offset 70]
0x86 (134)
1 to 24
0x13 (19)
125 34019 float
RWES
[`iP;3]
[ ip.3] Linearization (1 to 24)
Input Point 3
Set the value that will be
mapped to output 3.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
2.0 14398
[offset 70]
0x86 (134)
1 to 24
0xA (10)
126 34010 float
RWES
[`oP;3]
[ op.3] Linearization (1 to 24)
Output Point 3
Set the value that will be
mapped to input 3.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
2.0 14418
[offset 70]
0x86 (134)
1 to 24
0x14 (20)
127 34020 float
RWES
[`iP;4]
[ ip.4] Linearization (1 to 24)
Input Point 4
Set the value that will be
mapped to output 4.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
3.0 14400
[offset 70]
0x86 (134)
1 to 24
0xB (11)
128 34011 float
RWES
[`oP;4]
[ op.4] Linearization (1 to 24)
Output Point 4
Set the value that will be
mapped to input 4.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
3.0 14420
[offset 70]
0x86 (134)
1 to 24
0x15 (21)
129 34021 float
RWES
[`iP;5]
[ ip.5] Linearization (1 to 24)
Input Point 5
Set the value that will be
mapped to output 5.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
4.0 14402
[offset 70]
0x86 (134)
1 to 24
0xC (12)
130 34012 float
RWES
[`oP;5]
[ op.5] Linearization (1 to 24)
Output Point 5
Set the value that will be
mapped to input 5.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
4.0 14422
[offset 70]
0x86 (134)
1 to 24
0x16 (22)
131 34022 float
RWES
[`iP;6]
[ ip.6] Linearization (1 to 24)
Input Point 6
Set the value that will be
mapped to output 6.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
5.0 14404
[offset 70]
0x86 (134)
1 to 24
0xD (13)
132 34013 float
RWES
[`oP;6]
[ op.6] Linearization (1 to 24)
Output Point 6
Set the value that will be
mapped to input 6.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
5.0 14424
[offset 70]
0x86 (134)
1 to 24
0x17 (23)
133 34023 float
RWES
[`iP;7]
[ ip.7] Linearization (1 to 24)
Input Point 7
Set the value that will be
mapped to output 7.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
6.0 14406
[offset 70]
0x86 (134)
1 to 24
E (14)
134 34014 float
RWES
[`oP;7]
[ op.7] Linearization (1 to 24)
Output Point 7
Set the value that will be
mapped to input 7.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
6.0 14426
[offset 70]
0x86 (134)
1 to 24
0x18 (24)
135 34024 float
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E: EEPROM
S: User
Set
